Oilfield Drilling Spool on Sale
Xi'an TianRui Petroleum Machinery Equipment Co., Ltd.- Manufacturing Process：Forging
- Surface Treatment：Spray-Paint
- Operation Pressure：Atmospheric Pressure
- Material：Stainless Steel
- Transport Package：Wooden Case
- Specification：Various
Base Info
- Model NO.：JD-FS18-35
- Trademark：TR Solids Control
- Origin：Xi′ an, China
- Production Capacity：100PCS,Month
Description
Drill Spool Model
JD-FS18-35
JD-FS18-70
JD-FS18-105
JD-FS28-35
JD-FS28-70
JD-FS28-105
Nominal Diameter (mm)
Φ185
Φ185
180
280
Φ280
280
Working Pressure (MPa)
35
70
105
35
70
105
Intensive Pressure (MPa)
70
105
105
70
105
105
By-pass Diameter(mm)
Φ103
Φ103/Φ78
Φ103/Φ78
Φ103
Φ103/Φ78
Φ103/Φ78
Top and Bottom Connection Flange
API, 6B 1835 R46
API 6BX 1870 BX156
API 6BX 18-105 BX156
API, 6B 1835 R46
API 6BX18-105 BX156
API 6BX18-105 BX156
Side Connection Flange
API, 6B 103-35 R39
API 6BX 103-70 BX155 (Φ103)
API 6BX 103-105 ×155 (Φ103)
API, 6B 103-35 R39
API 6BX 103-105 ×155 (Φ103)
API 6BX103-105 ×155 (Φ103)
Sealing Time (S)
/
API 6BX 7870 BX154 (Φ78)
API 6BX 78-105 ×154 (Φ78)
/
API 6BX 78-105 ×154 (Φ78)
API 6BX78-105 ×154 (Φ78)
Applicable Temperature (ºC)
-29~+121
-29~+121
-29~+121
-29~+121
-29~+121
-29~+121
Overall Dimension
(L ×W ×H) (mm)
680×395
×584
830×480×600
880×505×700
950×585
×650
950×655×650
1,050×812×800
Weight (kg)
620
600
900
850
800
1,800
Drill Spool Model
JD-FS35-21
JD-FS35-35
JD-FS35-70
JD-FS35-105
JD-FS53-21
JD-FS54-14
Nominal Diameter (mm)
Φ346
Φ346
Φ346
Φ346
Φ530
Φ540
Working Pressure (MPa)
21
35
70
105
21
14
Intensive Pressure (MPa)
/
70
105
105
/
/
By-pass Diameter(mm)
/
Φ103
Φ103
Φ78
Φ103
Φ78
/
/
Top and Bottom Connection Flange
/
API, 6B1835 R46
API 6BX 18-105 BX156
API 6BX 18-105 BX156
/
/
Side Connection Flange
/
API, 6B103-35 R39
API 6BX 103-105 ×155 (Φ103)
API 6BX 103-105 ×155 (Φ103)
/
/
Sealing Time (S)
/
/
API 6BX 78-105 ×154 (Φ78)
API 6BX 78-105 ×154 (Φ78)
/
/
Applicable Temperature (ºC)
-29~+121
-29~+121
-29~+121
-29~+121
-29~+121
-29~+121
Overall Dimension
(L ×W ×H) (mm)
950×610
×600
1,100×672
×650
1,100×768
×650
1,390×880
×1,000
1,250×812
×800
1,250×812
×800
Weight (kg)
1,050
1,100
1,280
2,100
/
/
