• Model NO.：TRHJ
• Trademark：TR Solids Control
• Origin：China

Basic Info.

Model NO. TRHJ Trademark TR Solids Control Origin China

Product Description

HDD mud recovery system is developed, designed and manufactured to meet trenchless technology requirements at home and abroad and is applied in purification treatment of mud returned from underground during horizontal directional drilling process. Cuttings with big particle sizes are separated by shale shaker, mud cleaner and other solids control equipment. Mud materials required are added and evenly mixed for circulation via mud mixer to meet performance requirements for reuse. Mud is pumped into horizontal directional drilling mud system by mud pump for recycling.

Function of Oil High Quality Drilling Mud Solids Control System

1. With simple and compact structure, light weight, foldable or dismountable walkway and guardrail, being easy for transportation and installation.
2. Mud recovery system is designed with benefits as reasonable structure, favorable treatment process and a wide range of application fields.
3. Explosion-proof, rainproof and dustproof electric system to ensure construction safety and quality.
4. Multifunctional and integrated design to meet mud purification, recycling, preparation and storage, greatly reducing overall dimensions of the tank system, meeting HDD requirements on site and space.

Technical Data of Drilling Mud Solids Control System for HDD

Model	TRHDD-200	Model	TRHDD-500	TRHDD-1000
Capacity	200GPM (50m3 /h)	Capacity	500GPM (120m3 /h)	1000GPM (240m3 /h)
Shale Shaker	TRZS752S	Shale Shaker	TRZS703/TRZS585	TRZS703/TRZS585
Upper Screen Area	0.875m2	Screen Area	2.7m2	2X2.7m2
Upper Screen Area	1.35m2	Mud Cleaner	TRQJ250X1S-100X8N	TRQJ250X2S-100X12N
Hydrocyclone	4"	Mud Cleaner Mud Cleaner	10"×1pcs	10"×2pc
Hydroclycolone Qty	4 pcs	Desilter Cyclone	4"×8pcs	4"×12pcs
Supply Pump Model	TRSB4X3-12J	Bottom Screen Area	1.35m2	2.12m2
Slurry Pump Model	TRSB4X3-11J	Supply Pump	TRSB6X5-11J*2	TRSB8X6-11J*2
Mud Hopper	TRSLH100	Slurry Pump	TRSB6X5-12J	TRSB8X6-12J
Gross Power	44kW	Jet Mud Mixer	TRSLH150-35(37KW)	TRSLH150-35(45KW)
Total Volume	5m3	Mud Agitator	TRJBQ7.5	TRJBQ7.5
Dimension	4000×2360×2940mm	Gross Power	130kW	184kW
Weight	5500kg	Total Volume	15m3	30m3
		Dimension	10000×2360×4228mm	12100×2630×4438mm
		Weight	17000kg	20000kg

Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.




Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
