• Model NO.：TRPS284
• Capacity：140m3,H
• Vibration Motion：Dual Motion
• Motor Power：1.72kw+1.72kw+0.75kw
• Screen Specs.：(585*1165mm)*4PCS
• Screen Area：2.7m2
• Vibration Strength：≤8.5g(Adjustabe)
• Double Amplitude：7mm
• Adjustment Angle：-1°-+5°
• Ex Standard：Exdllbt4
• Weight：1700kg
• Dimension：2600×1645×1138mm
• Transport Package：Pallet or Wooden Case
• Specification：2100*1645*1380mm
• Trademark：TR Solids Control
• Origin：Xi′an, China
• HS Code：84748090
• Production Capacity：30 Sets, Month

(Model)TRPS584TRZS584Vibration MotionDual MotionDual MotionTreatment Capacity140m³/h110m³/hMotor Power1.72KW+1.72KW+0.75KW1.5KW+1.5KW+0.4KWScreen Specs.(585×1165mm)×4(585×1165mm)×3Screen Area2.7m²2.0m²Vibration Strength≤8.5G≤8.5GDouble Amplitude7mm7mmDeck Adjustment-3°~+3°-3°~+3°Ex StandardExdIIBt4/IECEX/A-TEXWeight1700kg1500kgDimension2600×1645×1138mm2100×1645×1380mmRemarkAbove data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3

Application



TRZS mud shale shaker is widely used in Drilling Waste Management, city bored piling, oil & gas drilling, tunneling construction, trenchless HDD, environment protection, Coal Bed Gas Solids Control System, micro-tunneling, Oil Mud Seperation, mining, Oil Sludge Dewatering Systems, Water Drilling etc.



Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.

Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
