• Model NO.：U701-A
• Trademark：HongYang
• Origin：China
• HS Code：84139100
• Production Capacity：50000PCS,Year

Until  today, a large  of fuel  service  stations   in domestic  use  fuel dispenser   located  on the ground.The   driven  motor

and  pump are  fixed  in dispenser's    enclosure.   Depending  on  the negative   pressure,   the dispenser   inject  product

into  the  tank  of  car. The  problem   is  the vaporization    of  product  when  the  head  is  over  4.27m.   In contrast,   the

submersible   turbine  pump put  in product  directly,  it drive  product  with  the positive   pressure  from tank  to dispenser

on the  ground.  The total  head  can reach  30m  without  any vaporization,    so the  product  tank can  be installed   more

distance  apart  from  station  when  design  it. In  addition,  due  to the  pump is  immersed  in product,   so the  product  is

directly   through  motor  bearings,   cooling  &  lubricating   them,  whenever   pump  is operating.   The  wear  is little  and

temperature   rise   is  lower,  with  the  results   that  the  trouble   decrease   and  service   life  is  longer.The   leaking   of

product  and noise  of operation   are also very  small,so  the  pollution  for environment   decrease.

Feature

♦3 stage turbine  pumps  are assembled  to the spline  of rotor  shaft. The

stator  is potted with  epoxy sealing  compound.  When  the motor is

started,  then the  bearings  are lubricated  by flowing  product.  Product

deliver  to nozzle  of oil gun through  check valve  and hose.

♦The electric  control  system  used 220V power  supply  is simple,  the

product  pipe and power  pipe in pump  set are separated,  so the

maintenance  is easy.

♦There is manual  pressure  relief  valve.  It is easy to relieve  the pressure  in

the piping  system  during routine  maintenance   or troubleshooting   and get

the product  back to storage  tank.

This avoid  any pollution  for envioronment   as other  pressure  relief

method.

♦Simple  servicing,  the pump  can be easily removed  from  the storage  tank

by unthreading  3 bolts.

Technique   Function:

♦Power  Supply:  Single  Phase, 220V,  50Hz

♦Motor  Power : 1100W (1.5HP)

♦Cur rent:   8.1A

♦Flow  Rate:   220~260L/Min

♦Maximum  Head:   30m

♦Products:   Gasoline,  Diesel.

♦Automatic   Reset  Ther mal  Protector  :

♦Trip up Temperature:   95ºC,Reset Temperature:   45ºC

♦Seal  Elastomers:   Fluorocarbon   parts with  better strength  and  fuel-resisting.

♦Capacitor  :  20uF,500VAC

♦Intake  Filter  Screen:   Stainless  steel construction   filters  particles  from  fuel, Not subject  to

the weight  of pump.

♦Diameter   of Riser : 114mm(4.5  ″)

♦Thickness   of Pipe:  4.8mm(0.188  ″)

Explosion-proof    approval:

This motor   has been tested  and granted  Ex approval.The   Ex-approval

is EX d IIA T3.Ex certificate   number  is CE991209.

Packing:

Packing  : 1set/carton

Carton  dimensions:  425 x 255 x 230mm

Net weight:  45kg

Gross weight: 46kg

Ordering   Specifications:

Product ID: U702-A

Product  name:

Submersible pump(include pump head and pump end)
