Oilfield Drilling Rig Equipment Mud Cleaner Desilter for Mud Clean
Shandong Beyond Petroleum Equipment Co., Ltd.- After-sales Service：After Service Accepted
- Certification：API
- Power Source：Electric
- Operation Pressure：Atmospheric Pressure
- Material：Cast Steel
- Type：Desilter
Base Info
- Voltage：220V~380V
- Capacity：120-160 M3,H
- Working Pressure：0.2~0.45MPa
- Transport Package：Export Container
- Specification：2310*1136*2085mm
- Trademark：Beyond
- Origin：China
- Production Capacity：10000PCS,Month
Description
Model
JZQJ100×10
JZQJ100×12
JZQJ100×14
JZQJ100×16
Hydrocyclone diameter
100mm
100mm
100mm
100mm
Working pressure
0.2~0.45MPa
0.2~0.45MPa
0.2~0.45MPa
0.2~0.45MPa
Capacity
120-160 m3/h
160-200 m3/h
200-220 m3/h
200-240 m3/h
Screen size
1240×585 mm
1240×585 mm
1240×585 mm
1240×585 mm
Screen spec
120-200 mesh
120-200 mesh
120-200 mesh
120-200 mesh
Inlet diameter
6″
6″
6″
6″
Outlet diameter
8″
8″
8″
8″
Motor power
0.5 kW
0.5 kW
0.5 kW
0.5 kW
Weight
680kg
720kg
740kg
780kg
Overall dimension
2310×1136×2085
2546×1136×2085
2646×1136×2085
2866×2018×2085
