API 10d Non Welded Single Piece Straight Bow Centralizer

Puyang Zhongshi Group Co., Ltd.
  • Certification：API
  • Surface Treatment：Spray-Paint
  • Centralizer Type：Elastic
  • Structure：Automatic Reversing
  • Material：Alloy
  • Type：Centralizer

Base Info

  • Model NO.：4.5", 5.5", 7", 13 3,8"
  • Material1：Aluminium
  • Material2：Alloy Steel
  • Height：550
  • Weight：15
  • Size：4.5"-20"
  • Material3：65mn
  • Transport Package：Wooden Case
  • Specification：5 1,2", 7", 9 5,8", 13 3,8"
  • Trademark：zhongshi
  • Origin：China
  • HS Code：9130
  • Production Capacity：30000PCS,Month

Description

Model(in)Hooping In-Dia.(mm)Hooping
thickness
 (mm)Hooping height(mm)Total Length(mm)Max. Out-Dia.(mm)Spring
Pieces5-1/2*8-1/2142-1483-590-120650±50225±557*9-5/8181-1863-590-120650±50255±567*8-1/2181-1863-590-120650±50235±568-5/8*12-1/4223-2283-590-120650±50330±589-5/8*12-1/4250-2553-590-120650±50330±5810-3/4*12-1/4274-2763-590-120650±50330±5913-3/8*17-1/2342-3473-590-120650±50450±51118-5/8*24476±13-590-120600±50610±51220*26510±13-590-120600±50660±512

Weld casing centralizer parameterModel(in)Hooping In-Dia.(mm)Hooping
 thickness
mm)Hooping height(mm)Total Length(mm)Max. Out-Dia.(mm)Spring
Pieces5-1/2*8-1/2142-1485-750-60650±50225±556*8-1/2154-1585-750-60650±50255±5513-3/8*17-1/2342-349850-60580450±5620*26510-518850-60650±50670±510
