API 10d Oilwell Slip on Non Welded One Piece Spring Centralizer
Puyang Zhongshi Group Co., Ltd.- Certification：ISO 9001:2000, ISO 9001:2008, API
- Surface Treatment：Polishing
- Centralizer Type：Elastic
- Structure：Bow
- Material：Cast Steel
- Type：Centralizer
Base Info
- Model NO.：6", 4.5" 5.75", 5.5"
- Height：350
- Weight：5
- Type1：Bow Spring Type
- Material 1：65mn
- Color：Red
- Bow Number：6
- Transport Package：Wooden Box
- Specification：5 1,2", 7", 9 5,8", 13 3,8", 20"
- Trademark：zs
- Origin：Puyang City
- HS Code：8431
- Production Capacity：10000PCS,Month
Description
Max O.D.Min.I.D. Overall Length in. mm mm mm in. mm in 7 208 8.189 157 6.181 1140 44.882 7-5/8 230 9.055 174.2 6.858 1140 44.882 9-5/8 282.5 11.122 220.5 8.681 1170 46.063 10-3/4 310 12.205 252 9.921 1211 47.677 13-3/8 384 15.118 315 12.402 1211 47.677 Casing Size Max O.D. Min.I.D. Overall Length in. mm mm mm in. mm in 7 208 8.189 157 6.181 1140 44.882 7-5/8 230 9.055 174.2 6.858 1140 44.882 9-5/8 282.5 11.122 220.5 8.681 1170 46.063
