High-Volume Drilling Tools Solids Control System & Dwm System Mud Cleaner.
Xi'an Boban Oil Tools Co., Ltd.- After-sales Service：24,7
- Warranty：12 Months
- Certification：CE, ISO 9001:2000, ISO 9001:2008
- Power Source：Electric
- Operation Pressure：Atmospheric Pressure
- Material：Carbon Steel
Base Info
- Model NO.：BBZQJ,Z 250*2-100*14-1
- Type：Mud Cleaner
- Transport Package：Pallet or Wooden Case
- Specification：3260x2040x2530mm
- Trademark：BOBAN & OEM
- Origin：China
- HS Code：84741000
- Production Capacity：25 Sets Per Month
Description
Model
ZQJ/Z 250*2-100*14-1
ZQJ/Z 250*2-100*10-2
Rated Frequency
50/60
50/60
Desander Cyclone Size
Φ250mm
Φ250mm
Desander Separation Point
40~74ΜM
40~74ΜM
Desander QTY& Material
Polyurethane 2ea
Polyurethane 2ea
Desander Capacity
200 M3/H
200 M3/H
Desander Inlet Pressure
0.15~0.35 Mpa
0.15~0.35 Mpa
Desilter Cyclone Size
Φ100mm
Φ100mm
Desander Separation Point
20~44ΜM
20~44ΜM
Desilter Capacity
155 M3/H.
115 M3/H.
Desander Inlet Pressure
0.25~0.45.
0.25~0.45.
Desander Separation Point
44~74ΜM
15-44ΜM
Desander QTY& Material
Polyurethane 14ea
Polyurethane 10ea
Bottom Shaker
GX/Z
GX/Z
Dimension
3260x2040x2530mm
3260x2040x2530mm
Weight
3515kg
3455kg
