Downhole Oil Tools Wireline Slickline Accelerator
Xi'an Boban Oil Tools Co., Ltd.- After-sales Service：24,7
- Warranty：12 Months
- Manufacturing Process：CNC Milling
- Surface Treatment：Phosphating
- Operation Pressure：N,a
- Material：Cast Steel
Base Info
- Model NO.：BBSA
- for Wire Size：0.108", 0.125"
- Connection：Un, Qls, Hdqrj
- Lenghth：2FT, 3FT,5FT
- Transport Package：Wooden Case
- Specification：1.25"~2.5"
- Trademark：BOBAN & OEM
- Origin：China
- HS Code：8431431000
- Production Capacity：30 PCS Per Month
Description
Basic Info.
Model NO. BBSA for Wire Size 0.108", 0.125" Connection Un, Qls, Hdqrj Lenghth 2FT, 3FT,5FT Transport Package Wooden Case Specification 1.25"~2.5" Trademark BOBAN & OEM Origin China HS Code 8431431000 Production Capacity 30 PCS Per MonthProduct Description
A wireline accelerator is wireline stretch simulator device used in conjunction with hydraulic or spring jars when jarring at shallow depths in the wellbore. The wirline accelerator is available in sizes from 1-1/2"to 3.00"OD and standard or H2S trim. Upward tension on the wireline compresses the spring with the accelerator assembly and the stored energy is transferred to the hydraulic or spring jars located further down the tool string.
Technical Parameters
| Size | Fishing Neck | Connection |
| 1.5" | 1.375" | 15/16UN |
| 1.75" | 1.375" | 15/16UN |
| 1.875" | 1.75" | 1-1/16UN |
| 2.125" | 1.75" | 1-1/16UN |
| 2.5" | 2.313" | 1-9/16UN |
| 3" | 2.313" | 1-9/16UN |
