• Model NO.：YDJ
• Transmission System：Mechanical
• Power Type：Diesel
• Transport Package：Standard Packing
• Specification：SGS
• Trademark：JIASONG
• Origin：China
• HS Code：8413110000
• Production Capacity：100000PCS, Year

Basic Info.

Model NO. YDJ Transmission System Mechanical Power Type Diesel Transport Package Standard Packing Specification SGS Trademark JIASONG Origin China HS Code 8413110000 Production Capacity 100000PCS/ Year

Product Description

Main Features
YDJ Series Mobile Fuel Unit, containing a large flow Flowmeter, Pump, Pipe, Mechanical Counter or Electronic Control Systems and Pulse Output etc, is applied to ship, public transportation vehicle, big bus, truck, train, military vehicle, aircraft, with advantage of high flow rate, convenience, long working life, etc.
According to users' requirements, electronic counter, mechanical preset counter, tubing, tubing dial(or motor-driven tubing dial), nozzle, prompt coupling, etc., are available for Mobile Fuel Unit.

Model	YDJ-50	YDJ-80	YDJ-100
Flow Rate	300L/min	800L/min	1200L/min
Size	50mm,2''	80mm.3''	100mm,4''
Accuracy	±0.2%	±0.2%	±0.2%
Repeatability	≤0.1%	≤0.1%	≤0.1%
Max working pressure	0.5MPa	0.5MPa	0.5MPa
Speed	780r/min	780r/min	780r/min
Motor	4Kw,50Hz,380V (220V)	7.5Kw,50Hz,380V (220V)	15Kw,50Hz,380V (220V)
Current	8A	15.4A	30A
