Zynj380/100 Big Torque Rotary Type Make-up and Breakout Machine

Huludao City Liaoxi Petroleum Machine and Tools Factory
  • Certification：ISO
  • Scope of Application：Φ60-Φ376 mm
  • Rated Torque：100kn.M
  • Type：Petroleum Drilling Tool & Accessory
  • Usage：Screw-on and Screw-off Machinery
  • Power Type：Electric

Base Info

  • Model NO.：ZYNJ380,100
  • Transport Package：Wooden Case
  • Origin：China
  • HS Code：8431431000
  • Production Capacity：6 Sets,Month

Description

Configuration NameTechnical SpecificationsQTYUnitPackingRemarks
ConsoleControl the operating handle according to the pressure gauge1
SetWooden cases
Hydraulic Power SystemMotor:power 22KW speed1460r/min, Required power:380V,frequency for:50HZ1
Set
Wooden casesHydraulic pump type: Variable plunger pumpTurnbuckle mechanism maximum working pressure: 16 mpaOil tank capacity:1540L
Make up/ breat out host machine
TailstockPipe dia.:Φ60-376mm1
Set
Wooden casesWalking speed :adjustableThe clamping accuracy: ≤ 1.5 mm
spinning wrenchPipe dia.:Φ60-376mm1
SetMake-up torque range:0.5-100KN.mBreak-out torque range:0.5-100KN.mTurnbuckle Angle: 360 hovering at any positionThe clamping accuracy: ≤ 1.5 mmBaseLength:5.5m1Set
