• Model NO.：TRG20A-055
• Power：5.5kw
• Pressure：0.3MPa
• Inlet：3"
• Outlet：3"
• Ex Standard：Exdiibt4
• Weight：323kg
• Transport Package：Pallet or Wooden Case
• Specification：2450× 340× 562mm
• Trademark：TR Solids Control
• Origin：Xi′an, China
• HS Code：84748090
• Production Capacity：100 Sets Per Month

ModelFlow RatePressurePower

Inlet

(Inch)

Outlet

(Inch)

Ex Standard

Weight

(Kg)

DimensionTRG10A-04010m³/h0.3Mpa4kw33ExdIIBt4/IECEX/A-TEX2452245×320×550mmTRG20A-05520m³/h5.5kw333232450×340×562mmTRG30A-07530m³/h7.5kw443862761×370×600mmTRG40A-11040m³/h11kw554543270×370×665mmTRG50A-11050m³/h11kw556083790×400×782mmTRG60A-15060m³/h15kw556493322×550×740mmTRG70A-22070m³/h22kw668753740×420×785mmTRG80A-22080m³/h22kw668753740×420×785mmTRG90A-22090m³/h22kw668753740×420×785mm





Competitive Advantages

1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.

Company Tenet

Customer's satisfaction is the highest pursuit of TR Solids Control.


Tag:

sludge screw pump,

screw displacement pump
