Sk-2000c Mud Logging Unit
Dongying Lake Petroleum Technology Co., Ltd.- After-sales Service:Required
- Warranty:6 Months
- Applicable Medium:Mud, Water
- Structure:Plug-In
- Standard:API 6A
- Transport Package:Standard
Base Info
- Model NO.:Required
- Specification:500*600*700
- Trademark:Required
- Origin:China
- Production Capacity:10000 PCS,Year
Description
SK-2000C Mud Logging Unit
Introduction
SK - 2000C bus mud logging unit using CAN bus data transmission technology, national patent product FID chromatograph, automatic monitor and record the related data of drilling process, drilling engineering data, formation characteristics and features, engineering accident forecast and analysis, is suitable for working in the environment explosion-proof requirement, has been widely used in the major domestic oil fields.
* To provide geologist formation characteristics and the characteristics and evaluation of reservoir etc
* Provide drilling engineer engineering data, achieve the goal of forecast and analysis of engineering accidents, improve the drilling efficiency, reduce the operation cost
* Prediction of drilling engineering accidents
Parameters
*Power device
FLP transformer
Input voltage: 380V(480V,440V,220V)
Input frequency: 50Hz
Output voltage :380V 5%
Output frequency:50Hz
- UPS Uninterruptible power supply
Input voltage:220V 10%
Input frequency: 35~65Hz
Output voltage :220V 2%
Output frequency:50 1Hz
Supply time:≥15min
- Instrument housing security index: insulation resistance between phase line and grounding conductor in computer is greater than 2 MW, the instrument must be equipped with good grounding device.
* Gas analyzer
- Component of nature gas analyzer
Analytic circle:90s/3min
Detect component:C1~nC5
Component of nature gas Measuring range:30×10-6 ~1 mol/mol (CH4);
30×10-6 ~30×10-2mol/mol (C2H6).
The minimum concentration of detector:30×10-6 mol/mol (CH4,C2H6);
Total hydrocarbon Measuring range:50×10-6 ~1 mol/mol;
Rapeatability error:±2.5%;
Baseline shift:±0.1mV/h;
Noise: 0.05mV;
Resolution ratio:C1 and C2 retention time ≥5s.
- Non-hydrocarbon component in natural gas analyzer
Detect object:CO2;
Minimum detectable concentration:CO2 0.1%;
Measuring range:CO2 0.1%~100%;
Baseline shift:measuring range 1%/7d;
Rapeatability error:±5%.
* Sensor
- pump stroke/table speed sensor:measuring range:0-1920 stroke /min,
- Rotary table torque sensor :measuring range:0~6MPa
- Stand pipe pressure sensor:measuring range:0~42MPa
- Casing pressure sensor:measuring range:0~68MPa
- Hook weight pressure sensor:measuring range:0~6MPa
- Drilling fluid temperature sensor:measuring range:0~125ºC
- Density sensor:measuring range:0~3g/cm
- Electrical conductivity sensor:measuring range: 0~50ms/cm,0~300ms/cm
- Mud outlet flow sensor:measuring range:0~100% (relative flow)
- Liquid level sensor:measuring range: 0~5m
- Drawwors sensor:measuring range:0~999 times, set the hook position:0~50m
- H2S sensor:measuring range:0~100ppm, response time:T80<30s
