Sk-Cms Mud Logging Unit
Dongying Lake Petroleum Technology Co., Ltd.- After-sales Service：Required
- Warranty：6 Months
- Applicable Medium：Mud, Water
- Structure：Plug-In
- Standard：API 6A
- Transport Package：Standard
Base Info
- Model NO.：Required
- Specification：500*600*700
- Trademark：Required
- Origin：China
- Production Capacity：10000 PCS,Year
Description
SK-CMS Mud Logging Unit
SK - CMS is a mud logging system designed by Shenkai with the international advanced level. The instrument integrate many advanced technology such as explosion-proof CAN bus technology, fast chromatographic techniques, MWD technology, field geological analysis instrument joint application technology and so on. It becomes the comprehensive information interpretation evaluation center.
SK - CMS has been widely accepted by people who engaged in logging services and used in the United States, Russia, India, Pakistan and so on more than 10 countries and regions, not only in the domestic oilfields. It has becomes a real famous national brand.
Parameters
* Body Structure Design: DNV 2.7-1 certificate
* Pressurized Explosion-proof Electrical Design satisfies with requirements of IEC 60079-13 and other relevant certificate
* Outdoor Environment Temp: -40ºC~60ºC
* Indoor Operating Temp: 0ºC~30ºC
* Relative Humidity: ≤90%
* Indoor positive pressure: 50Pa~120 Pa
* Power Input: Volt: 220V/380V/440V/480V ±5% 3P
* Frequency: 50Hz/60Hz±5%
* Power: 20KVA
* Transformer Output: Volt: 380V ± 5% 3P+N
Frequency: 50Hz/60Hz±5%
* Electrical Protection: Overload, short, leakage and lack-phase protection
* Explosion-proof Control: auto-monitor combustible gas, H2S, smoke, air flow rate and indoor pressure. In cases of the concentrations of pressure loss, smoke, combustible gas and H2S exceeds the threshold, system gives acoustic and light alarm, then shutdown the power automatically after self analysis.
