• Model NO.：JHBD
• Standard：API
• Transport Package：Standard Export
• Trademark：BODA
• Origin：China
• HS Code：8431431000
• Production Capacity：5000 Ea,Year

Basic Info.

Model NO. JHBD Standard API Transport Package Standard Export Trademark BODA Origin China HS Code 8431431000 Production Capacity 5000 Ea/Year

Product Description

Double Drum Wireline Unit
 This wireline unit could be mounted on different truck chassis. Applying new technology "Regulating while Logging",it could complete well test and water injection at one time, with cost saving and efficiency improved. Through new technology promotion, it reflects market trend and demand, as best alternative to existing water-injected well wireline unit.★ Feature & benefitDouble drum for basic slickline and E-Line operationsHydraulic system: closed loop or open loopControl: Air or handElectric spooling fine adjustment systemWinter ice scraping systemCompact design and light weight ★ StructureImported dual-way variable displacement piston pumpImported multiway proportional reversing valveLow-speed torque hydraulic motorHydraulic oil tank assemblyCable drum assemblySlickline drum assemblyClutch for drums optionAutomatic spooling systemCable fine adjusting systemMeasuring systemDual brake and transverse assemblySlip ring assemblyControl pannelDual mechanical counterElectric depth and weight indicatorControlling gauge
   Technical Parameter



Performance	3000m	5000m
E-line size	Ф3.2/Ф3.5 mm	Ф3.2/Ф3.5 mm
Slickline size	Ф2.4/Ф2.7 mm	Ф2.4/Ф2.7 mm
Max. pull	>10KN/15KN	>10KN/15KN
Max. pull speed	7m/s	7m/s
Drum rotation speed(RPM)	0-320r/min	0-320r/min
Hydraulic rated pressure	20MPa	20MPa
Line spooling way	Automatic/ fine adjustment	Automatic/ fine adjustment
Brake way	Two modes	Two modes
Clutch switching mode	Manual or air	Manual or air
Drum hand body	Yes	Yes
Electric depth and weight indicator	Mounted	Mounted
