Skid Mounted Hydraulic Wireline Unit

Zhenjiang Boral Machinery and Equipment Co., Ltd.

Certification：ISO 9001:2008, API
Power Source：Hydraulic
Operation Pressure：Vacuum
Applicable Medium：Mud, Water, Natural Gas, Crude Oil
Structure：Plug-In
Material：Cast Steel

Base Info

Model NO.：JHBD
Standard：API
Transport Package：Standard Export
Trademark：BODA
Origin：China
HS Code：8431431000
Production Capacity：5000 Ea,Year

Description

Stationary winch(YJC-G)Logging depth3000m4000m6000m7500mSlickline sizeФ2.2,Ф2.4Ф2.2,Ф2.4, Ф2.6Ф2.2,Ф2.4, Ф2.6Ф2.2,Ф2.4, Ф2.6Max. Pressure20MPa20MPa20MPa20MPaRated Pressure16MPa16MPa16MPa16MPaLine Pull7KN7KN,15KN7KN,15KN7KN,15KNPull speed7m/s7m/s7m/s7m/sRPM0-320 r/min0-320 r/min0-320 r/min n0-320 r/minLine coilingautomaticautomaticautomaticautomatic

Skid Mounted Hydraulic Wireline Unit
