• Model NO.：JZ
• Specification：customized
• Trademark：JPIM
• Origin：China
• HS Code：8431431000
• Production Capacity：10000sets,Year

Basic Info.

Model NO. JZ Specification customized Trademark JPIM Origin China HS Code 8431431000 Production Capacity 10000sets/Year

Product Description

IA/D conversion technology, widely applied in electronic floor scale,electronic truck scale and so on alike static weighing system equipped with 1~8 load cell.



Feature:

1.Compatible with all functions of model XK3190-A9;

2.∑-Δ high precision A/D conversion method, able to process input signal from -16mV to 18mV

3.Good consistency, no need to re-calibrate a scale if change the former indicator, high precision

4.DC power socket with anti-connect and anti-short circuit protection;

5.With strong anti-disturbance function





Standard Function:

1.AC/DC power supply, standard chargeable battery

2.7-bits 0.8 inch LED display, 3-level battery indications

3.Able to setup zero-tracking range, zero(auto/manual) range

4.With 2-point calibration correction function, 2 compensation calibration methods

5.Able to save 1001 weighing records, 1000 truck records consisting of truck ID and corresponding tare weight, 201 records of goods

6.Able to print across and upright weighing bill

7.Able to print different statistical reports

8.Standard RS232 communication interface(RS422/RS485 optional)

9.Standard scoreboard interface with current loop

10.Standard parallel print interface

11.Able to connect assigned thermal printer

12.XK3190-A9+P with built in printer



Technical Parameter:

1.A/D conversion method: ∑-Δ

2.Input signal range:-16mV~18mV

3.A/D conversion speed: 10times/sec.

4.A/D conversion code: 1 million code

5.Load cell excitation: DC 5V
