Xq89/3yh New Tubing Power Tong
JIANGSU YOUYAO PETROLEUM MACHINERY CO., LTD.- Manufacturing Process：CNC Milling
- Surface Treatment：Without Processing
- Operation Pressure：API
- Material：Plastic
- Transport Package：650 X 430 X 550 mm
- Specification：2-3,8"-3-1,2;
Base Info
- Model NO.：YXQ89
- Trademark：YOUYAO
- Origin：China
- HS Code：8413910000
- Production Capacity：1000 Sets Per Month
Description
Technical parameters:
1.Main tong
(1) adaptation of the 2 3/8" , 2 7/8" , 3 ½" tubing
(2) rated high-grade torque 1.1 kN.m (8179 ft-lbs)
(3) Rated low torque 3.0 kN.m (2230ft-lbs)
(4) rated high-grade speed 100 r/min
(5) Rated low speed 30 r/min
(6) Open Size 95 mm
(7) shipments quality 100 kg (220lbs)
2. Back tong
(1) Adaptation of the 23/8" , 2 7/8" , 3 ½" - -
And thickening of tubing coupling
(2) openings Size 116 mm
(3) shipments quality 53kg (116.6 lbs)
3, portfolio clamp Dimension 650 x 430 X 550 mm
4, rated pressure system 10 MPa (1450psi)
5, rated Oil Supply 80 L/min (21gpm)
Advantages:
1, the first use of lever-type power tong steering mechanism (patented technology), for the board to resolve the roller-board climb in the slope of the first problem, and the new double-column fracture difficult to block sales.
2, a brake brake connection with a plate agencies (patented technology), film and not friction brake disc, as well as ordinary connectivity boards, panels at the same time the amount of braking and no connection between the plate spline connection, a decrease of Difficulty processing, improved connectivity strength.
3, a back clamp + rack plunger rod drive mechanism (patented technology), completely resolve the original back clamp cylinder leakage problems.
4, Xuanzhou back clamp reset using small hand-Gear + board, easy to operate, safe and reliable.
