Drillable 7" Anti-Rotating Top Cementing Rubber Plugs Price
Puyang Zhongshi Group Co., Ltd.- Certification：ISO 9001:2000
- Material：Rubber
- Type：Cementing Plug
- OEM：Avaliable
- Sample：Avaliable
- Application：Oil Drilling Application
Base Info
- Model NO.：ZS18
- Cementing Plug Type：Non Rotation Type
- Transport Package：Wooden Case
- Specification：customize size are avaliable
- Trademark：ZS
- Origin：Henan
- Production Capacity：5000 Piece,Pieces Per Month
Description
Casing Weight RangeWiper Fin O.D Working
Temperature Working
Pressure Burst
Pressure Hardness Size(in) mm in mm in 4 1/2" 14.14-17.26 9.50-11.60 110 4.331 -30ºC to 150ºC ≥15MP 1MP-2MP 75-95 5" 17.11-35.86 11.50-24.10 122 4.803 5 1/2" 20.83-39.88 14.00-26.80 135 5.315 7" 25.30-56.55 17.00-38.00 170 6.693 7 5/8" 35.72-63.69 24.00-42.00 185 7.283 9 5/8" 53.57-79.62 36.00-53.50 235 9.252 13 3/8" 71.43-107.15 48.00-72.00 333 13.11 -30ºC to 150ºC ≥10MP 20" 139.89-197.93 94.00-133.00 498 19.606
Features of cementing plug
1. Anti-rotating cementing plugs are manufactured of graded rubber that is fused upon a phenolic core core.
2. The top plug is used when dual plug system is not required.The bottom cementing plug can be used when dual plug system is required.
3. These plugs are completely PDC drillable.
4. Plug can be ordered for higher operating temperature and operation in either synthetic or mud fluids.
6. Available in 4 1/2" to 20 "sizes + any special sizes.
Temperature
Pressure
Pressure
Features of cementing plug
1. Anti-rotating cementing plugs are manufactured of graded rubber that is fused upon a phenolic core core.
2. The top plug is used when dual plug system is not required.The bottom cementing plug can be used when dual plug system is required.
3. These plugs are completely PDC drillable.
4. Plug can be ordered for higher operating temperature and operation in either synthetic or mud fluids.
6. Available in 4 1/2" to 20 "sizes + any special sizes.
