Dissolvable Plug for Fracturing Service
Dongying Zhaoxin Industry and Trade Co, Ltd.- After-sales Service：After Sales Service
- Warranty：6 Months
- Manufacturing Process：CNC Milling
- Surface Treatment：Without Processing
- Operation Pressure：10000psi
- Material：Magnesium
Base Info
- Model NO.：5-1,2"
- Application：Dissolvable Plug
- Transport Package：Wooden Case
- Specification：7"
- Trademark：ZX
- Origin：China
- HS Code：8431431000
- Production Capacity：100 Set Per Month
Description
Basic Info.
Model NO. 5-1/2" Application Dissolvable Plug Transport Package Wooden Case Specification 7" Trademark ZX Origin China HS Code 8431431000 Production Capacity 100 Set Per MonthProduct Description
Dissolvable FRAC PLUGMaterial:aluminium magnesium
Tensile strength:257.8MPa
Yield strength:158.6MPa
Elongation:4.4%
Density: 1.7 ~ 2.3g/cm3
Specification :
lIt consists of dissolvable metals and rubber.lUpper and lower double slip design ensures reliable pressure seal.lTo meet the construction requirements of large displacement 70MPa (10000psi).lLarge diameter 50mm to meet the demand of backflow.lDissolution rate can be adjusted according to well condition.lNo residual wellbore after dissolution to achieve full diameter.lNo need for tubing plug, saving cost, reducing operation risk and improving production efficiency.lCan provide 3-1/2", 4-1/2", 5", 5-1/2"casing dimensions.
