Kht Series Hydraulic Casing Power Tong Kht 14000
Dongying Lake Petroleum Technology Co., Ltd.- After-sales Service:No Overseas Service Provided
- Warranty:1 Year
- Certification:ISO 9001:2000
- Power Source:Hydraulic
- Operation Pressure:2200 Psi
- Applicable Medium:Pipe
Base Info
- Model NO.:KHT 14000 casing power tong
- Structure:Not Applicable
- Material:Alloy
- Certificates:API ISO
- Master Tong Range:4"-14′′
- Back up Tong Range:4"-15 1,2"
- Max Torque:75000 FT*Lbs
- Transport Package:Standard Export Packing
- Specification:refer to product description
- Trademark:Lake
- Origin:China
- HS Code:8431431000
- Production Capacity:20 Sets Per Month
Description
Overview
Product DescriptionModel KHT7625 KHT9625 KHT13625 KHT14000 Range of Master Tong Φ73-194 Φ73-245 Φ101-346 Φ101-356 2 7/8"-7 5/8" 2 7/8"-9 5/8" 4"-13 5/8" 4"-14" Range of Backup Tong Φ73-219 Φ73-267 Φ101-394 Φ101-394 2 7/8"-8 5/8" 2 7/8"-10 1/2" 4"-15 1/2" 4"-15 1/2" Low Gear Rated of Torque 34000 N.m 34000 N.m 42000 N.m 100000 N.m 25000 ft/lbs 25000 ft/lbs 31000 ft/lbs 75000 ft/lbs Low Gear Rated Speed 8 RPM 6.5 RPM 8.4 RPM 3 RPM Rated Operation Pressure 14 Mpa 14 Mpa 14 Mpa 17.2 Mpa 2000 PSI 2000 PSI 2000 PSI 2500 PSI Rated Flow 150 LPM 150 LPM 150 LPM 187.5 LPM 40 GPM 40 GPM 40 GPM 50 GPM Master Tong Dimension: L×W×H 1350×660×1190 1500×790×1045 1508×857×1194 1750×1080×1240 53" ×26" ×47" 59" ×31" ×41.1" 59.4" ×33.8" ×47" 69" ×42.5" ×48.8" Combined Tong Dimension: L×W×H 1350×660×1750 1500×790×1750 1508×1082×1900 1750×1080×2050 53" ×26" ×69" 59" ×31" ×69" 59.4" ×42.6" ×74.8" 69" ×42.5" ×80.7" Master Tong Weight 550 kg 800 kg 650 kg 1500 kg 1210 lbs 1760 lbs 1433 lbs 3300 lbs Combined Tong Weight 825 kg 1220 kg 1250 kg 2150 kg 1820 lbs 2680 lbs 2750 lbs 4730 lbs Detailed PhotosHow to contact us
