API-Oilfield Drilling Mud Shale Shaker

Xi'an TianRui Petroleum Machinery Equipment Co., Ltd.
  • Certification：CE, ISO 9001:2000, ISO 9001:2008, API
  • Mesh Shape：Rectangle
  • Sieve Mesh Number：20-325
  • Layer：Multilayer
  • Material：316L
  • Type：Linear

Base Info

  • Model NO.：TRZS584
  • Color：Green
  • Transport Package：Wooden
  • Specification：2966X1600X1280
  • Trademark：TR Solids Control
  • Origin：China
  • HS Code：84748090
  • Production Capacity：5000

Description

(Model)TRPS703TRPS584-4TRZS703TRZS584Vibration MotionBalanced Elliptical MotionLinear MotionTreatment Capacity130m³/h140m³/h120m³/h130m³/hMotor Power1.94+1.0kw1.94+1.0kw1.5KW×21.72KW×2Screen Specs.(700×1250mm)×3(585×1165mm)×4(700×1250mm)×3(585×1165mm)×4Screen Area2.6m²2.7m²2.6m²2.7m²Vibration Strength≤7.1G≤7.1G≤7.1G≤7.1GDouble Amplitude7mm7mm6mm6mmDeck Adjustment-1°~+5°-1°~+5°-1°~+5°-1°~+5°Ex StandardExdIIBt4 / IECEX / A-TEXWeight1630kg1618kg1620kg1600kgDimension2770×1785×1690mm2966×1600×1280mm2770×1785×1690mm2966×1600×1280mmRemarkAbove data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3.
