• Model NO.：Fh 28-70
• Colour：Customer Requirement
• Condition：New
• Transport Package：Container
• Specification：3 1,8",3 1,2",4 1,8",4 3,4",5",6",6 1,4′,6 1,2",6
• Trademark：UPET
• Origin：China
• HS Code：73061900
• Production Capacity：200000 PCS,Year

Overview Product Description

Carmeron Shaffer Hydrill type 5000 psi FH 28-70 API Annular BOP

Our API 16A hydril annular BOP can be used in work over and drilling operations equipped with hydril control systems. The BOPs are designed and manufactured in full conformity to the API 16A standard. The annular BOP mainly consists of a body, a header, a rubber core, and a piston. The inner rubber core is interchangeable. While the annular BOP can be used independently, it normally works with a single or a double BOP.It can seal the drilling tool or well bore efficiently, preventing oil well blow outs. Its anti H2S performance conforms to the NACE MR 0175 standard.Model2FZ18-212FZ18-35Rated working pressure(psi)30005000Nominal diameter(in)7  1/167 3/8Strength pressure test(psi)60007500Oil cylinder working pressure(psi)1200-15001200-1500Piston stroke(mm)100100Metal temperature class-29~121ºC-29~121ºCNonmetal temp. class-18~121ºC-18~121ºCOil cylinder closed chamber volume2 x 1.75L2 x 1.75LOil cylinder open chamber volume2 x 1.50L2 x 1.50LRam closed interval(s)<15<15Ram specification2 3/8" 2 7/8" 3 1/2" 4 1/2" blind ram2 3/8" 2 7/8" 3 1/2" 4 1/2" blind ramBolt quantity and diameter12-M30 x 3 x 21012-M36 x 3 x 230Ring gasketR45R46Dimension(mm)1350 x 380 x 6381350 x 395 x 656Weight(lb)17171780Operating pressureBore (in)(psi)180-7 1/16230-9280-11350 13 5/8430-16 3/4480-18 3/4530-20 3/4540-21 1/4680-26 3/4140-20000105-15000SSSS70-10000SSSSS35-5000SSSSSSS21-3000SSSSSSS14-2000S Detailed Photos
