• Model NO.：JG-35
• Specification Level：Psl3
• Applicable Standard：API16c
• Lateral Diameter：65mm
• Weight：2700kg
• Material Grade：Ee
• Rated Temperature：-29°c~121°c
• Transport Package：Pallet or Wooden Case
• Specification：2891*2086*1150mm
• Trademark：TR Solids Control
• Origin：Xi′an, China
• HS Code：84749000
• Production Capacity：300 Sets , Month

ModelJG-35Applicable StandardAPI16CMain Diameter(mm)103Lateral Diameter(mm)65Dimension2891*2086*1150Weight(kg)2700Rated Working Pressure(Mpa)35Material GradeEESpecification LevelPSL3Rated Temperature-29°C~-121°C



Technical Parameters:


DescriptionChoke manifoldKill manifoldmodelJG/S2-35JG/SY-35JG/SY2-70JG/S2Y2-105YG-35YG-70YG-105Main ND and bypass ND in(mm)3 1/8×2 1/16(80×52) 4 1/16×2 9/16(103×65) 4 1/16×3 1/16(103×78)Working pressure3000(21)3000(21)500(35)10000(70)15000(105)psi(MPa)5000(35)10000(70)Working temperature °C(°F)P.U -29~121 (-20~250)Working mediumMud, oil (w/ H₂S)Control typeDouble wing structure manual throttle valveDouble wing structure hydraulic throttle valveThree-way structure hydraulic/manual throttle valveFour-way double hydraulic/manual throttle valveDouble-wing structure pneumatically controled
