Desilter Hydrocyclone Dn150mm Inlet Size with 180m3/H Capacity

Xi'an TianRui Petroleum Machinery Equipment Co., Ltd.
  • Certification：ISO 9001:2008
  • Power Source：Electric
  • Operation Pressure：Atmospheric Pressure
  • Material：Stainless Steel
  • Type：Desilter
  • Hydrocyclone Qty：12nos

Base Info

  • Model NO.：TRCN100-12N
  • Capacity：180m3,H
  • Separation Point：15μm-44μm
  • Inlet Size：Dn150mm
  • Outlet Size：Dn200mm
  • Working Pressure：0.25-0.4MPa
  • Bottom Shaker：Trzs752
  • Weight：1150kg
  • Transport Package：Pallet or Wooden Case
  • Specification：1835*1230*1810mm
  • Trademark：TR Solids Control
  • Origin：Xi′an, China
  • HS Code：84748090
  • Production Capacity：20 Sets , Month

Description

ModelTRCN100-4NTRCN100-6N/8NTRCN100-12N/16NTRCN100-20NCapacity60m390m3/120m3180m3/240m3300m3Cyclone Specs4"Cyclone Qty4 pcs6pcs/8pcs12pcs/16pcs20pcsWorking Pressure0.25-0.4MpaInlet SizeDN100mmDN125mmDN150mmDN150mmOutlet SizeDN125mmDN150mmDN200mmDN200mmSeparation Point15μm -44μmBottom ShakerTRZS60TRZS60TRZS752TRZS703Dimension1510*1160*2000mm1510*1360*2250mm1835*1230*1810mm2770*1785*1810mmWeight550kg560kg/580kg1150kg1950kgRemarkAll desilter could be customized without bottom shaker.



Desilter Hydrocyclone Dn150mm Inlet Size with 180m3/H CapacityDesilter Hydrocyclone Dn150mm Inlet Size with 180m3/H CapacityDesilter Hydrocyclone Dn150mm Inlet Size with 180m3/H CapacityDesilter Hydrocyclone Dn150mm Inlet Size with 180m3/H Capacity




TR Solids Control is a professional desilter designer and manufacturer in China with high reputation. We will provide our clients high quality product with reasonable price and attentive service . At the same time we offer good performance desander, mud cleaner, shale shaker, decanter centrifuge, jet mud mixer, vacuum degasser, mud agitator, shear pump, screw pump, centrifugal pump, and mud recycling system for oil & gas drilling, tunnel construction, bored pile project, HDD trenchless etc. Welcome to the field visit.



Application in Drilling Solids control



TRCN series mud desilter is currently used in trenchless HDD, oil & gas drilling, city bored piling, Drilling Waste Management, tunneling construction, micro-tunneling, environment protection, Coal Bed Gas Solids Control System, mining, Oil Sludge Dewatering Systems, Oil Mud Seperation, Water Drilling etc.



Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
