API 6A Tubing Heads for Wellhead

Cixi Fly Pipe Equipment Co., Ltd.
  • Drilling Program：Single Stage
  • Applicable Medium：Mud, Water, Natural Gas, Crude Oil
  • Connection Form：Flange
  • Well Type：Chassis Well
  • Installation Position：Overwater
  • Structure：Vertical

Base Info

  • Model NO.：tubing head
  • Type：Dry
  • Standard：API 6A
  • Product Name：API 6A Casing Spool,Oilfield Equipment,Wellhead EQ
  • Transport Package：Plywooden Case
  • Specification：1,2" - 48"
  • Trademark：Fly
  • Origin：Zhejiang Province, China
  • HS Code：8431431000
  • Production Capacity：50000tons,Month

Description

Bottom

Flange

Top

Flange

Dimensions

Weight

Lbs/Kg

A, inch / mm

B, inch / mm

C, inch / mm

11"

2,000

7-1/16"

3,000

23.12/587.2

6.76/171.7

7.00/177.8

550/249

3,000

7-1/16"

3,000

23.12/587.2

6.76/171.7

7.00/177.8

600/272

5,000

26.25/666.8

6.76/171.7

7.00/177.8

670/304

9"

3,000

26.25/666.8

8.25/209.6

8.75/222.3

750/340

5,000

26.25/666.8

8.25/209.6

8.75/222.3

800/363

5,000

7-1/16"

5,000

26.25/666.8

6.76/171.7

7.00/177.8

880/399

10,000

31.25/793.8

6.76/171.7

7.00/177.8

856/388

9"

10,000

31.25/793.8

8.25/209.6

8.75/222.3

1249/567

10,000

7-1/16"

10,000

32.62/828.5

6.76/171.7

7.00/177.8

1318/598

15,000

33.25/844.6

6.76/171.7

7.00/177.8

------

9"

10,000

32.62/828.5

8.25/209.6

8.75/222.3

1700/771

13-5/8"

2,000

7-1/16"

3,000

23.12/587.2

6.76/171.7

7.00/177.8

445/202

9"

3,000

23.12/587.2

8.25/209.6

8.75/222.3

655/297

3,000

7-1/16"

3,000

26.25/666.8

6.76/171.7

7.00/177.8

670/304

5,000

26.25/666.8

6.76/171.7

7.00/177.8

805/365

9"

3,000

26.25/666.8

8.25/209.6

8.75/222.3

705/320

5,000

26.75679.5

8.25/209.6

8.75/222.3

715/324

5,000

11"

10,000

30.25/768.4

10.00/254.0

10.88/276.4

1754/796

Tubing Heads feature a versatile straight bore design for single and multiple completions. This design accepts all  series tubing hangers and easily converts from a single completion to multiple completions with the addition and alignment pin(s).Available Sizes
  • Available with 7-1/16" nominal bowl
  • Compatible with 7-5/8" production casing
Outlets
  • Line Pipe Outlets
  • Studded Side Outlets
Casing Hanger Compatibility
  • C-21 and C-22 slip-type casing hangers
  • Mandrel style casing hangers
Manufacturing Standard
  • API-6A, PSL-1, DD, L-U, PR-1 (3M-5M)
  • API-6A, PSL-2, DD, L-U, PR-1 (10M)
Tubing Hanger Compatibility
  • TWC tubing heads accept a wide variety of tubing hanger styles including mandrel and wrap-around
Bottom Preparations
  • PE/BG bottom, for use with PE secondary seal bushing (Standard)
  • HPE bottom, for use with HPE secondary seal bushing for high pressure applications (Available upon request)
Availablility
  • Additional sizes available upon request • Available with ET (Integral) style lock screws
  • Flanged top Tubing Heads available with slip-on weld or threaded bottoms
  •
