Horizontal Directional 200 Gpm Trenchless Drilling Mud System

Xi'an TianRui Petroleum Machinery Equipment Co., Ltd.
  • Certification:ISO 9001:2000, ISO 9001:2008
  • Power Source:Electric
  • Operation Pressure:Atmospheric Pressure
  • Material:Carbon Steel
  • Type:HDD System
  • Capacity:200gpm

Base Info

  • Model NO.:TRHDD-200
  • Shale Shaker:Trzs752s
  • Hydrocyclone:4"
  • Hydrocyclone Qty:4 PCS
  • Supply Pump Mode:Trsb4*3-12j
  • Slurry Pump Model:Trsb4*3-11j
  • Mud Hopper:Trslh100
  • Gross Power:44 Kw
  • Weight:5500kg
  • Dimension:4000*2360*2940mm
  • Transport Package:by Container
  • Specification:TRHDD-1000
  • Trademark:TR Solids Control
  • Origin:Xi′an, China
  • HS Code:84749000
  • Production Capacity:10 Sets , Month

Description

ModelTRHDD-200ModelTRHDD-500TRHDD-1000Capacity200GPM (50m3 /h)Capacity500GPM (120m3 /h)1000GPM (240m3 /h)Shale ShakerTRZS752SShale ShakerTRZS703/TRZS585TRZS703/TRZS585

Upper Screen Area

0.875m2

Screen Area

2.7m22X2.7m2

Upper Screen Area

1.35m2

Mud Cleaner

TRQJ250X1S-100X8NTRQJ250X2S-100X12N

Hydrocyclone

4"

Mud Cleaner

Mud Cleaner

10"×1pcs10"×2pc

Hydroclycolone Qty

4 pcs

Desilter Cyclone

4"×8pcs4"×12pcs

Supply Pump Model

TRSB4X3-12J

Bottom Screen Area

1.35m22.12m2Slurry Pump ModelTRSB4X3-11JSupply PumpTRSB6X5-11J*2TRSB8X6-11J*2Mud HopperTRSLH100Slurry PumpTRSB6X5-12JTRSB8X6-12JGross Power44kWJet Mud MixerTRSLH150-35(37KW)TRSLH150-35(45KW)Total Volume5m3Mud AgitatorTRJBQ7.5TRJBQ7.5Dimension4000×2360×2940mmGross Power130kW184kWWeight5500kgTotal Volume15m330m3  Dimension10000×2360×4228mm12100×2630×4438mm  Weight17000kg20000kg
 Horizontal Directional 200 Gpm Trenchless Drilling Mud SystemHorizontal Directional 200 Gpm Trenchless Drilling Mud SystemHorizontal Directional 200 Gpm Trenchless Drilling Mud SystemHorizontal Directional 200 Gpm Trenchless Drilling Mud System



We have explored the international market, provided high-quality products, competitive prices and excellentservice in recent years. Our products are exported to Europe, America, theMiddle East, South America, Southeast Asia, Australia etc, obtained the customer affirmation and the faith.



Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
