• Model NO.：LWY355X1257
• Warranty：1 Year
• Application：Oilfield
• Colour：Customer Requirement
• Transport Package：Container
• Specification：API#5, API#6, API7#, API8#
• Trademark：UPET
• Origin：China
• HS Code：8431431000
• Production Capacity：24 Sets,Year

Overview Product Description

LW series is a normal decanting centrifuge mode of our company, they are ideal choices for separating particles in drilling mud. Decanting Centrifuge separate the suspending fluids using  the principle of centrifugal action, the suspending fluids is pushed into the rotor drum through the inlet pipe and the fluid hole of the spiral feeder. Under the influence of centrifugal force, solid phase particles are pushed to the internal wall of the drum, then to the mud export of the small end of the drum and excreted. But the fluids is excreted from the overflow hole of the large end. Such cycle is in order to achieve the purpose of continuous separation.

High speed decanting centrifuge are effective for separation.

Model

LWY355X1257

Motor power

37 kw

Oil box

>180 L

Speed of bowl

0-4000 rpm

Max G-force

3180

Bowl diameter

14''

Bowl length

1257 mm

Power

380V/50Hz or 460V/60Hz

Feed pump(progressive cavity pump)

7.5kw, model is XG070b01JF

Main pressure of system

21 Mpa

Main pressure of screw

14.5 Mpa

Discharge pressure

16 Mpa

Max boost pressure

3 Mpa

Dimension

3100 mm x 1620 mm x 2055 mm

Weight

4000 kg

Features of Decanter Centrifuge

• Detailed Photos
