• Model NO.：BW250
• Piston Stroke：100 mm
• Bore：80 65 mm
• Handle Position：1 2 3 4
• Pump Speed (S.P.M)：200, 116, 74, 42,
• Output Vol.(S.P.M)：250, 145, 90, 52, 166, 96, 60, 35
• Volumatric Efficiency：85%
• Overall Efficiency：72%
• Power：15 Kw
• Multiple Grooved Pulley D.P.：B*410mm
• Transport Package：in Wooden Case or in Standard Container
• Specification：CE, ISO 9001, SGS
• Trademark：Leadcrete
• Origin：Henan, China
• HS Code：8413509090
• Production Capacity：1000 Set,Year

Basic Info.

Model NO. BW250 Piston Stroke 100 mm Bore 80 65 mm Handle Position 1 2 3 4 Pump Speed (S.P.M) 200, 116, 74, 42, Output Vol.(S.P.M) 250, 145, 90, 52, 166, 96, 60, 35 Volumatric Efficiency 85% Overall Efficiency 72% Power 15 Kw Multiple Grooved Pulley D.P. B*410mm Transport Package in Wooden Case or in Standard Container Specification CE, ISO 9001, SGS Trademark Leadcrete Origin Henan, China HS Code 8413509090 Production Capacity 1000 Set/Year

Product Description

BW250 250L Large Output Mine Horizontal triplex drilling mud pump

Detail description: geological drilling triplex mud pump
The pump is one of the principle equipment for geological drilling. It delivers the enough volume circulating mud water of desired characteristic under pressure into the well to bring the rock clastic up to ground, to cool the drill bit to lubricate the drill tool and to protect the wall of the well. So the function of mud pump affects the efficiency of drilling and safety in production directly. BW-250 Mud pump is a horizontal, triplex, single acting reciprocating piston pump. It has the advantages of multi-speed shift gears for variable displacement, construction, light weight, readily movable and easy to be operated etc.BW-250 Mud Pump is provided with two kinds of liner, 80mm is for core frilling of ordinary bore, 65 mm is for core drilling of small bore with diamond bit. The pump can be driven by electric motor or diesel engine according to the requirement of the customer in order.



Specifications
1. Small size, light weight
2. Long life
3. Easy handling
4. Delivery time within 15 working days


type	Horizontal Triplex Reciprocating Acting piston pump
Stroke	100mm
Bore	80   65 mm
Handle position	1 2 3 4
Pump Speed(s.p.m)	200 116 74 42
output vol.(s.p.m)	250, 145, 90, 52, 166, 96, 60, 35
Discharge pressure(Mpa)	2.5, 4.5, 6, 6, 4, 6, 7, 7
Volumetric efficiency	85%
Total efficiency	72%
input power	15KW
Multiple grooved pulley D.P.	B*410mm
Input speed of pump (r.p.m)	500r/min
Max. suction head	2.5m
Inside diameter of suction hose	76mm
Inside diameter of discharge	51mm
Weight	760KG
Overall dimensions(L*W*H)	1100*995*650mm
