• Model NO.：TRSB3*2-10J
• Lift：20m
• Impeller Diameter：10inch
• Power：7.5kw
• Electric System：50Hz
• Ex Standard：Exdiibt4,Iecex,a-Tex
• Weight：380kg
• Transport Package：Wooden Case or Pallet
• Specification：1398*490*717mm
• Trademark：TR Solids Control
• Origin：Xi′an, China
• HS Code：84748090
• Production Capacity：50 Sets , Month

ModelPowerFlowLift(m)EfficiencyNPSHElectricTRSB8×6-14J75KW320m³/h40m65%550HZTRSB8×6-12J355m³/h43m66%4.860HZTRSB8×6-13J55KW290m³/h33m64%5.550HZTRSB6×5-12J196m³/h48m61%360HZTRSB6×5-13J45KW180m³/h34m60%350HZTRSB5×4-14J149m³/h61m58%4.660HZTRSB6×5-12J37KW160m³/h30m60%350HZTRSB5×4-12J112m³/h45m58%4.660HZTRSB6×5-11J30KW120m³/h21m62%2.550HZTRSB5×4-12J112m³/h37m57%4.660HZTRSB5×4-12J22KW90m³/h30m56%4.550HZTRSB5×4-10J105m³/h30m57%4.260HZTRSB5x4-11J18.5KW90m³/h24m56%4.550HZTRSB4x3-12J55m³/h46m48%460HZTRSB4x3-13J15KW50m³/h40m48%4.550HZTRSB4x3-11J54m³/h35m47%460HZTRSB4x3-12J11KW45m³/h30m47%450HZTRSB3x2-12J28m³/h45m40%3.160HZTRSB3x2-12J7.5KW45m³/h24m46%450HZTRSB3x2-11J25m³/h35m41%3.160HZTRSB3x2-11J5.5KW20m³/h23m39%350HZ



Application



TRSB series centrifugal pump is widely used in trenchless HDD,  oil & gas drilling, Drilling Waste Management, city bored piling, tunneling construction, Water Drilling, mining, Oil Sludge Dewatering Systems, Coal Bed Gas Solids Control System, Oil Mud Seperation, environment protection etc.



Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.

Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
