• Model NO.：LLW
• Operation Type：Automatic Continuous Operation
• Machine Control：PLC Control
• Centrifugal Type：Basket Centrifuge
• Moc：Stainless Steel
• Bearing：NSK,SKF
• Screen Touch：Optional
• Dicharge：Scroll Discharge
• Braking System：Dynamic Braking
• Type：Petroleum Drilling Machine
• Usage：Well Drilling Machinery
• Power Type：Electric
• Transport Package：Seaworth Packing for Machine and Electric Cabinet
• Specification：CE ISO
• Trademark：Huada
• Origin：China
• HS Code：84211990
• Production Capacity：100 Sets Per Month

Basic Info.

Model NO. LLW Operation Type Automatic Continuous Operation Machine Control PLC Control Centrifugal Type Basket Centrifuge Moc Stainless Steel Bearing NSK/SKF Screen Touch Optional Dicharge Scroll Discharge Braking System Dynamic Braking Type Petroleum Drilling Machine Usage Well Drilling Machinery Power Type Electric Transport Package Seaworth Packing for Machine and Electric Cabinet Specification CE ISO Trademark Huada Origin China HS Code 84211990 Production Capacity 100 Sets Per Month

Product Description

LLW Drilling Cuttings Dryer

Working Principles

The feed suspension is introduced to the centrifuge through a feed tube and into the feed distribution chamber, and is jetted into the bowl through the hole near the cone point of the scroll. Under centrifugal force the solids separate from the liquid and settle against the bowl wall, while the clarified liquid exits over the overflow screen. The solids in the conical drum are conveyed up from the smaller end to the bigger end while the scroll turns at a slightly different speed. The bigger diameter is, the bigger centrifugal force produces to separate the liquid/solids. The solids are dried when they are drained out the drum.

Features
1. Bowl and scroll and other main parts are made of stainless or titanium materials resisting corrosion. The cone angle of the bowl is 10° Or 20°
2. The reversed cone ring designed particularly at the front-end of the cone-shaped bowl makes the bowl achieve double dehydration function screening and sedimentation.
3. Continuous feeding, separating, cleaning, dewatering and solid discharging, with complete continuity.
4. Specifically custom-built screening metal lathing with a thickness of 1.5mm and longer service life.
5. Large handling capacity and good cleaning effect.
6. Frequency conversion control, stepless speed of the bowl is adjustable.
7. The differential speed of the scroll is adjustable.
8. Independent lubrication station with simple and reliable lubrication and good cooling performance.
9. Safety protection: Rotating speed detection, over vibration protection, motor overload and overheat protection and scroll zero differential protection can be configured.

Models	Basket Dia (mm)	Rotation rate of basket (r/min)	Relative Centrifugal force	Productivity m3/h	Power of motor (kw)	Weight (kg)	Overall Dimensions (l*w*h) (mm)
LLW320	320	2630	1240	1-5	7.5	700	1350*1050*1000
LLW350	350	3000	1770	2-8	11	1000	1400*1250*1150
LLW400	400	2750	1700	3-10	15	1300	1500*1350*1250
LLW450	450	2500	1580	5-15	22	1500	1600*1400*1300
LLW530	530	2000	1190	8-20	30	2000	1700*1450*1400
LLW630	630	1800	1140	10-30	37-45	2500	1980*1440*1740
LLW800	800	1400	870	15-50	55-75	4000	2300*2200*1750
LLW1000	1000	950	500	20-80	75-90	6000	3000*2400*2300
LLW1200	1200	780	400	30-100	90-110	8000	3200*2800*2600
