55kw Capacity Mud Vertical Cutting Dryer for Oil Mud separation

Xi'an TianRui Petroleum Machinery Equipment Co., Ltd.
  • Certification：ISO 9001:2008
  • Power Source：Electric
  • Operation Pressure：Atmospheric Pressure
  • Material：Stainless Steel
  • Type：Vertical Cutting Dryer
  • Capacity：30-50t,H

Base Info

  • Model NO.：TRCD930B-VFD
  • Basket Diameter：930mm
  • Basket Gap：0.25-0.5mm
  • Rotary Speed：0~900r,Min
  • Air Inlet Pressure：0.69MPa
  • Air Tool Air Supply：1.8m3,Min
  • Main Motor Power：55kw
  • Oil Pump Power：0.55kw
  • Weight：6000kg
  • Transport Package：Pallet or Wooden Case
  • Specification：2750*2130*1800mm
  • Trademark：TR Solids Control
  • Origin：Xi′an, China
  • HS Code：84748090
  • Production Capacity：20 Sets Per Month

Description

ModelTRCD930CTRCD930B-VFDCapacity(T/h)30-50T/hBasket Max.Diameter930mmBasket Gap0.25-0.5mmRotary Speed900 r/min0-900 r/minAir knife Air Inlet Pressure0.69MpaAir Tool Air Supply1.8m3/minFuel Tank Volume60LMain Motor Power(Kw)55KwOil Pump Power(Kw)0.55KwWeight5900kg6000kgDimension2750*2130*1800mm

55kw Capacity Mud Vertical Cutting Dryer for Oil Mud separation
55kw Capacity Mud Vertical Cutting Dryer for Oil Mud separation55kw Capacity Mud Vertical Cutting Dryer for Oil Mud separation55kw Capacity Mud Vertical Cutting Dryer for Oil Mud separation
55kw Capacity Mud Vertical Cutting Dryer for Oil Mud separation

Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.

Company Tenet

Customer's satisfaction is the highest pursuit of TR Solids Control.
