Drilling Equipment 4 1/2" Slip on Welded Sprail Solid Body Rigid Centralizer
Puyang Zhongshi Group Co., Ltd.- Certification：ISO 9001:2008
- Surface Treatment：Spray-Paint
- Centralizer Type：Rigid
- Structure：Slider
- Material：Cast Steel
- Type：Centralizer
Base Info
- Model NO.：cast steel centralizer
- OEM：Avaliable
- Sample：Avaliable
- Vane：Stright Vane, Spiral Vane,
- Centralizers Type：Cast Steel Rigid Centralizers
- Transport Package：Wooden Case
- Specification：3"~20"
- Trademark：ZS
- Origin：Henan
- HS Code：8431
- Production Capacity：30000 Piece,Pieces Per Month
Description
Description
Rigid centralizers are with high supporting force and low starting force , thus enabling the casing smoothly down and at the same time stay at a high level.
Sizes ranging from 4-1/2" to 20", custom size are available
Spiral vane: reducing drag force.
Features
1. Application:in deviated and horizontal wells, liner overlaps, and shoe joints.
2. Suitable for either cased or open hole.
3. Made of high tensile, solid, cast steel, for shock, impact, and corrosion resistance.
4. Vane ends are beveled 30 degrees relative to casing centralizer to provide excellent lead into restrictions, and reduced drag when running into hole.
5. Wide vanes distribute load from the casing string into the well bore without gouging.
6. The design of the vanes keeps running forces at a minimum.
7. The 360 degrees overlapping solid vane provides maximum wall contact and fluid swirl. Thus reduced flow area between the spiral blade and produces a vortex motion of the fluids for more fluid velocity with direction.
