API 7K Xq114-6b Tubing Power Tong
Dongying Lake Petroleum Technology Co., Ltd.- After-sales Service:No Overseas Service Provided
- Warranty:1 Year
- Certification:ISO 9001:2000
- Power Source:Not Applicable
- Operation Pressure:Not Applicable
- Applicable Medium:Pipe
Base Info
- Structure:Not Applicable
- Material:Stainless Steel
- Certificates:API ISO
- Transport Package:Standard Export Packing
- Specification:refer to product description
- Trademark:Lake
- Origin:China
- HS Code:8431431000
- Production Capacity:2000 Sets Per Month
Description
Overview
Product DescriptionFeaturesModel ZQ127/25 ZQ162/50 ZQ203/100 ZQ203-125 Size range Drill pipe mm 65-127 85-162 114-203 in 2 3/8-3 1/2 2 3/8-5 2 7/8-8 Casing mm 65-127 114.3-153.7 in 2 3/8-3 1/2 4 1/2-5 1/2 Oil pipe mm 65-127 88.9-141.3 in 2 3/8-3 1/2 3 1/2-4 1/2 Max. torque kN.m 25 50 100 125 ft.lbf 18440 36880 73750 92200 Speed (high gear) rpm 65 60 40 40 Speed (low gear) rpm 10.5 4.1 2.7 2.7 Air pressure MPa 0.5-0.9 psi 72-130 Pressure rating MPa 12 16 16.6 20.7 psi 1740 2030 2400 3000 Flow rating L/min 120 114 gpm 31.7 30 Shifting distance mm 1000 1500 in 39.4 59 Size mm 1110×735×815 1570×800×1280 1760×1000×1360 1760×1080×1360 in 44×31×32 62×31×50 69×39×53 69×40.5×53 Weight kg 620 1500 2400 2650 lb 1360 3310 5290 5840 Detailed PhotosHow to contact us
Product Parameters
