F1000 Triplex Single-Acting Reciprocating Piston Mud Pump

Glorytek Industry (Beijing) Co., Ltd.
  • Certification：Pei, Ce, Atex, ISO, OIML
  • Power Source：Electric
  • Operation Pressure：Atmospheric Pressure
  • Material：Cast Steel
  • Type：Mud Pump
  • Rated Input Power(Kw/HP)：738,1000

Base Info

  • Model NO.：F1000
  • Rated Stroke (Stroke/Min)：140
  • Usage：Well Drilling Machinery
  • Transport Package：Sea-Worthy Packing
  • Trademark：Glorytek
  • Origin：China
  • Production Capacity：15 Sets,Month

Description

TypeHorizontal 3-cylinder single acting piston pumpGear typeHerringbone gearRated input power(kw/hp)738/1000Gear Ratio4.207:1Rated stroke (stroke/min)140LubricationForced and flashingStroke length(mm/min)254/ 10"Valve cavityAPI-6#Connection dimension of suction side12" ( 305mm)Connection dimension of discharge side5" Flange 5000psiThe weight of main machine (kg/pound)18790/41425Profile dimensions(LxWxH)4120x2260.6x1778mm 163 2/8" x89" x70"Stroke/minLiner Size (mm/inch),170160150140130120110Pressure Rating (Mpa psi)16.6
(2140)18.8
(2725)21.4
(3100)24.5
(3555)28.4
(4125)33.4
(4840)34.5
(5000)KWHPDisplacement: L/S150799107143.24(685)38.30(607)33.66(533)29.33(465)25.29(401)21.55(341)18.10(287)140746100040.36(639)35.75(566)31.42(498)29.37(434)23.60(374)20.11(318)16.90(268)13069292937.47(594)33.20(526)29.13(462)25.42(403)21.92(347)18.67(296)15.69(248)12063985734.59(548)30.64(485)26.93(427)23.46(372)20.23(320)17.24(273)14.48(229)11058678631.71(502)28.09(445)24.93(391)21.51(341)18.54(294)15.80(250)13.28(210)10053371428.83(457)25.53(404)22.44(355)19.55(310)16.86(267)14.36(227)12.07(191)1  0.2883(4.569)0.2553(4.047)0.2244 (3.557)0.1955(3.099)0.1686(2.672)0.1436 (2.277)
