• Model NO.：F500
• 2：Triplex Single Acting Piston Pump
• Usage：Mud Pump
• Transport Package：Seaworthy Packing
• Specification：SGS
• Trademark：Glorytek
• Origin：China
• Production Capacity：300 Sets,Month

TypeHorizontal 3-cylinder single acting piston pumpGear typeHerringbone gearRated input power(kw/hp)373/500Gear Ratio4.286:1Rated stroke (stroke/min)165LubricationForced and flashingStroke length(mm/min)190/ 7.5"Valve cavityAPI-6#Connection dimension of suction side8" ( 203mm)Connection dimension of discharge side4" Flange 5000psiThe weight of main machine (kg/pound)9770/21540Profile dimensions(LxWxH)3658x2702x2207mm 144x106 3/8x86 7/8inchStroke/
minLiner Size (mm/inch),170160150140130120110100Pressure Rating (Mpa psi)9.4
(1365)10.6
(1540)12.1
(1750)13.9
(2010)16.1
(2335)18.9
(2740)22.5
(3260)27.2
(3945)KWHPDisplacement: L/S17038451536.75(582)32.56(516)28.61(453)24.93(395)21.49(340)18.31(290)15.39(244)12.72(201)*165*37350035.67(565)31.60(501)27.77(440)24.19(383)20.86(330)17.77(281)14.93(236)12.34(195)15033945532.43(514)28.73(455)25.55(400)21.99(348)18.96(300)16.16(256)13.58(215)11.22(178)14031642430.27(480)26.81(425)23.56(373)20.53(325)17.70(280)15.08(239)12.67(201)10.47(166)13029439428.11(445)24.90(394)21.88(347)19.06(302)16.44(260)14.00(222)11.77(186)9.73(154)12027136425.94(411)22.98(364)20.20(320)17.60(279)15.17(240)12.93(205)10.86(172)8.98(142)11024933323.78(37721.07(334)18.52(293)16.13(255)13.91(220)11.85(188)9.96(158)8.23(130)1  0.2162(3.427)0.1915(3.036)0.1683(2.668)0.1466(2.324)0.1264(2.004)0.1077(1.707)0.0905(1.435)0.0748(1.186)
