Top-Selling Tatsuno Type Flowmeter for Fuel Dispenser with UL Ce Approval
Hongyang Group Co., Ltd.- Manufacturing Process：Casting
- Surface Treatment：Spray-Paint
- Operation Pressure：Vacuum
- Material：Cast Aluminum
- Type：Parts of Fuel Dispenser
- Transport Package：Standard Carton Case
Base Info
- Model NO.：U101-B
- Trademark：HongYang
- Origin：China
- HS Code：84139100
- Production Capacity：50000PCS,Year
Description
Materials:
Buna-N
| Technical Specifications: | |
| ♦ | Discharge rate of each revolution: 0.5L |
| ♦ | Rotary direction of rotary bar: Clock wise |
| ♦ | Environmental condition:-40ºC~+70ºC |
| ♦ | Minimum adjusting increasing quantity: 0.05% |
| ♦ | Working pressure: 0.12Mpa-0.3Mpa |
| ♦ | Repeat error: not exceed ±0.1% |
| Features : | |
| ♦ | Micro-accurate 4-piston,positive displacement type meter with rotary valve, exterior adjustment and double oil lip seal for long life. |
| ♦ | External structure achieved by single body design of components. |
| ♦ | Excellent accuracy: ±0.2% with high flow through-put |
| ♦ | 100% tested before Ex-Factory |
| Package: | |||
| Product ID | Net Weight | Cross Weight | Dimension |
| U101-B | 5.3kg/case of 1 | 5.5kg/case of 1 | 27x23x22cm/case of 1 |
| Ordering Specifications: | |
| Product ID | Product Name |
| U101-B | Flowmeter |
