SK-2000FC Mud Logging Unit

Introduction

SK - 2000 FC bus type positive pressure explosion-proof mud logging unit used explosion-proof CAN bus data transmission technology and national patent chromatograph and positive pressure explosion-proof technology, is suitable for offshore platform or environment neeed explosion-proof requirements, has been used in China international market such as Kazakhstan, Mongolia, Ecuador, etc.

*  Positive pressure explosion-proof technology, ensure the safety of the field working environment and staff
*  To provide geologist formation characteristics and the characteristics and evaluation of reservoir etc
*  Provide drilling engineer engineering data, achieve the goal of forecast and analysis of engineering accidents, improve the drilling efficiency, reduce the operation cost
*  Prediction of drilling engineering accidents

Parameters

*  Power device
    FLP transformer
    Input voltage: 380V(480V,440V,220V)
    Input frequency: 50Hz
    Output voltage :380V 5%
    Output frequency:50Hz
- UPS Uninterruptible power supply
    Input voltage:220V 10%
    Input frequency: 35~65Hz
    Output voltage :220V 2%
    Output frequency:50 1Hz
    Supply time:≥15min
- Instrument housing security index: insulation resistance between phase line and grounding conductor in computer is greater than 2 MW, the instrument must be equipped with good grounding device.
*  Gas analyzer
- Component of nature gas analyzer
    Analytic circle:90s/3min
    Detect component:C1~nC5
    Component of nature gas Measuring range:30×10-6 ~1 mol/mol (CH4);
    30×10-6 ~30×10-2mol/mol (C2H6).
    The minimum concentration of detector:30×10-6 mol/mol (CH4,C2H6);
    Total hydrocarbon Measuring range:50×10-6 ~1 mol/mol;
    Rapeatability error:±2.5%;
    Baseline shift:±0.1mV/h;
    Noise: 0.05mV;
    Resolution ratio:C1 and C2 retention time ≥5s.
- Non-hydrocarbon component in natural gas analyzer
    Detect object:CO2;
    Minimum detectable concentration:CO2 0.1%;
    Measuring range:CO2 0.1%~100%;
    Baseline shift:measuring range 1%/7d;
    Rapeatability error:±5%.
*  Sensor
- pump stroke/table speed sensor:measuring range:0-1920 stroke /min,
- Rotary table torque sensor :measuring range:0~6MPa
- Stand pipe pressure sensor:measuring range:0~42MPa
- Casing pressure sensor:measuring range:0~68MPa
- Hook weight pressure sensor:measuring range:0~6MPa
- Drilling fluid temperature sensor:measuring range:0~125ºC
- Density sensor:measuring range:0~3g/cm
- Electrical conductivity sensor:measuring range: 0~50ms/cm,0~300ms/cm
- Mud outlet flow sensor:measuring range:0~100% (relative flow)
- Liquid level sensor:measuring range: 0~5m
- Drawwors sensor:measuring range:0~999 times, set the hook position:0~50m
- H2S sensor:measuring range:0~100ppm, response time:T80<30s
*  Geological instrument
- Carbonate analyzer
    Measuring range:0~100% carbonate
    precision:1%
- Mudstone determinator
    Measuring range:1~3g/cm
    Minimum sample weight :0.05g
    Resolution:0.01g/cm
- Fluorscence analyzer
    Power supply:220VAC,50Hz
    Power:40W
    Thermal vacuum degasser
    Power supply:220VAC,50Hz
    Heating power :300W
    System vacuum degree:≤1.3KPa
    System sealing:after vacuum up to 1.3KPa, Visual vacuum table going down no more than 0.26KPa with 2 hours after partition;
    Volume of mud bottle:250ml
*  Electric degasser
 Working voltage :three phase 380VAC
 Power:370W
 Speed:1400rpm
 Explosion-proof grade :ExdIIBT4
*  Software system
 Windows 2000Serve or Windows;
 Conversion between metric and imperial;
 Real-time data acquisition, calculation, dynamic display of the rig, showed more;
 Automatic acousto-optic alarm and other functions;
 Offer a variety of function module and a display screen;
 Provide remote transmission of data interface, meet the needs of different user needs
