• Model NO.：SEV
• Control System：Servaview for Frac
• Control Mode：Auto and Manual
• Transport Package：Export Standard
• Trademark：SERVA
• Origin：China
• HS Code：8430412200
• Production Capacity：1000 Units , Year

Basic Info.

Model NO. SEV Control System Servaview for Frac Control Mode Auto and Manual Transport Package Export Standard Trademark SERVA Origin China HS Code 8430412200 Production Capacity 1000 Units / Year

Product Description

The Fracturing Instrument Control Van is applicable fro inland oilfield well acidizing, sand control and fracturing services. It has two control modes: auto control mode and the manual control mode. The van may be used to monitor and control the whole service processes. During a job, the van can be used to achieve the centralized control over multiple pumping units, blenders, liquid additives conveying equipments and fracturing fluid mixing truck.It can implement the real-time acquisition, displays, records, job data processes, storage, and print out job data report and service curves.
The van consists of the following components: the chassis, the main cabin, vibration absorber system, power system, communication system, air conditioning system, computer data acquisition system, fracturing equipment control system and website monitoring system.
The entire configuration, carborne performance, load distribution and non-grade highway property of equipment are accordance with national standard. The equipment ensures safe and reliable operation. the main technical parameters and performance all meet national industrial standards and legislation requirement.
Our product is enrolled in national special viehicle catalogue announcement. The trademark is SERVA.
Function
-- SERVAview for FRAC, data acquisition and processing software.
-- Fracturing truck manual control system.
-- APS-II remote network control system for tracturing truck.
-- ABS-II, remote network control system for blender.
-- Remote network control system for liquid additive skid.
-- Remote network control system for mixing truck.
-- Fracturing design analysis software.
-- Portable data acquisition system
Available Options
-- The chassis may introduce the domestic or the imported overseas brand in accordance with the state engine discharge standard.
-- Equipped with generator or UPS as requied by customers.
-- Equipped with manual/network control system for fracturing truck depending upon customer's request.
-- Remote control box for fracturing truck
-- Data transimission via satellite or GPS
-- Motorola communication system
-- Moveable/retractable camera and auxiliary control devies.
Parameters of typical products

Truck model	SEV5112TYB	SEV5140TYB	SEV5151TBC	SEV5152TBC
Chassis	Dongfeng DF1140B	North Benz ND2162E48J	MAN TGS18.360	BENZ Actros2032
Wheelbase (mm)	5000	4800	5800	5800
overall dimension (mm)	9260x2500x3800	8900x2500x3940	10230x2500x3980	10210x2500x3980
Inner dimension of cabin (mm)	6512x2396x2100	5906x2396x2100	7200x2396x2100	7000x2500x2100
Total weight (kg)	11000	13400	14830	14830
Engine model	Cummins ISDe21030	Weichai WP10.300N	D2066LF42	BENZ OM501LA IV/4
Engine displacement (ml)	6700	9726	10518	11946
Engine rating (Kw)	155	221	265	235
