API Oil Casing Slip Cms Type Well Drilling Casing Pipe Handling Tools
Dongying Lake Petroleum Technology Co., Ltd.- After-sales Service：No Overseas Service Provided
- Warranty：1 Year
- Certification：ISO 9001:2000
- Power Source：Not Applicable
- Operation Pressure：Not Applicable
- Applicable Medium：Pipe
Base Info
- Model NO.：all model
- Structure：Not Applicable
- Material：Alloy
- Certificates：API 7A
- Transport Package：Standard Export Packing
- Specification：refer to product description
- Trademark：Lake
- Origin：China
- HS Code：8431431000
- Production Capacity：2000 Sets Per Month
Description
Overview
Product Description FeaturesSpecification
Casing O.D.
Weight
Total No. Of Segments
Use in Insert Bowl No.
in
mm
kg
lb
4-1/2 ~ 5
114.3 ~ 127
76
168
9
API or No.3
5-1/2 ~ 6
139.7 ~ 152.4
71
157
9
6-5/8
168.3
89
196
12
7
177.8
83.5
184
12
7-5/8
193.7
75
166
12
8-5/8
219.1
82
181
13
9-5/8
244.5
87
192
14
No.2
10-3/4
273.1
95
209
15
11-3/4
298.5
118
260
17
No.1
13-3/8
339.7
117
258
18
16
406.4
140
308
21
Match with Relevant Casing Busing
18-5/8
473.1
166.5
367
25
20
508
174
383
26
24
609.6
201
443
30
26
660.4
220
486
33
30
762
248
546
37
