API Mud Tank of Solid Control System for Oil Well Drilling Fluid

Shandong Beyond Petroleum Equipment Co., Ltd.
  • After-sales Service：After Service Accepted
  • Certification：API
  • Power Source：Electric
  • Operation Pressure：Atmospheric Pressure
  • Material：Cast Steel
  • Type：Mud Tank

Base Info

  • Transport Package：Packing in Nude
  • Specification：21050X3800X3120 cm
  • Trademark：Beyond
  • Origin：China
  • Production Capacity：10000PCS,Month

Description

 Model

JZS280-3P

JZS270-4P

JZS240-3P

JZS220-3P

JZS180-2P

Motor power

2×2.2 kW

2×2.2 kW

2×2.2 kW

2×2.2 kW

2×1.3 kW

Screen area(m2)

3×0.833×1.15

4×0.585×1.165

3×0.7×1.15

3×0.7×1.05

2×0.833×1.15

Shaking intensity(g)

7.2 g

7.2 g

7.2 g

7.2 g

7.2 g

Discharge capacity

42 l/s

40 l/s

35 l/s

30 l/s

26 l/s

Adjustable range

-2°~+6°

-2°~+6°

-2°~+6°

--2°~+6°

-2°~+6°

Overall dimension,mm

3140×1980×1540

2970×1980×1530

2700×1980×1540

2700×1900×1540

2300×1940×1300

Weight

2000 kg

2000kg

1900kg

1700 kg

1200kg
