• Model NO.：Z331-115
• Transport Package：Wooden Case
• Specification：3-1,2" 4-1,2" 5-1,2" packer
• Trademark：ZX
• Origin：China
• HS Code：8431431000
• Production Capacity：100 Set Per Month

Basic Info.

Model NO. Z331-115 Transport Package Wooden Case Specification 3-1/2" 4-1/2" 5-1/2" packer Trademark ZX Origin China HS Code 8431431000 Production Capacity 100 Set Per Month

Product Description

CUP PACKER

Cup packer is a kind of self-sealing packer , which relies mainly on the interference contact between sealing elements and the inner wall of the casing to achieve the purpose of sealing the tubing and casing annular

Since the cup packer itself has no slip , so it has a good safety and high reliability.Moreover ,there is no damage to the casing pipe

Features:
1.the structure of the cup packer is simple , it has the advantage of convenient construction and operation , reliable sealing and no anchoring machanism .It can be used in vertical wells , deflecting wells and horizontal wells.
2.The cup of the product can be facing fixed( maintain the pressure from two directions) or fixed in the same direction.cup can be fixed in any direction and it is easy to dismount


type	Max OD(mm)	Length(mm)	Min ID(mm)	Working pressure	connection	Suitable size
Z33-114	114	587	62	≤25	EUE/NUE	5-1/2"
Z33-143	143	706	62/76	≤25	EUE/NUE	6-5/8"
Z33-150	150	706	62/76	≤25	EUE/NUE	7"
