• Model NO.：TRSLH150-30
• Matching Pump：Trsb5*4-14j
• Motor Power：37kw
• Work Pressure：0.25 to 0.4MPa
• Inlet Diameter：150mm
• Nozzle Diameter：30mm
• Hopper Dimension：600*600mm
• Burden Speed：<60kg,Min
• Weight：1300kg
• Dimension：2000*1650*1100mm
• Transport Package：Iron or Wooden Case
• Specification：2000*1650*1100mm
• Trademark：TR Solids Control
• Origin：Xi′an, China
• HS Code：84748090
• Production Capacity：30 Sets Per Month

ModelTRSLH150-50TRSLH150-40TRSLH150-30TRSLH100Matched PumpTRSB8×6-13J(55kw)TRSB6×5-13J(45kw)TRSB5×4-14J(37kw)TRSB4X3-11J(15kw)Treating Capacity240m3/h180m3/h120m3/h60m3/hWorking Pressure0.25~0.40Mpa0.25~0.40Mpa0.25~0.40Mpa0.25~0.40MpaInlet Diameter150mm150mm150mm100mmNozzle Diameter50mm40mm30mm30mmHopper Size750x750mm750x750mm600x600mm600x600mmBurden Speed≤100kg/min≤80kg/min≤60kg/min≤40kg/minWeight1600kg1450kg1300kg1100kgDimension2200*1700*1200mm2200*1700*1200mm2000*1650*1100mm2000*1650*1100mm
