Jzqj 250*1 Single Hydrocyclone Desander
Shandong Beyond Petroleum Equipment Co., Ltd.- After-sales Service：Video Technical Support, Online Support, Spare PAR
- Warranty：1 Year
- Certification：CE, ISO 9001:2000, ISO 9001:2008
- Mesh Shape：Circular
- Layer：Single Layer
- Material：Steel
Base Info
- Model NO.：JZQJ 250*1
- Type：Linear
- Hydrocyclone Diameter：250mm
- Working Pressure：0.2~0.45MPa
- Capacity：100 M3,H
- Screen Size：1240*585 mm
- Screen Spec：120-200
- Inlet Diameter：6"
- Outlet Diameter：8"
- Transport Package：Wood Box
- Specification：2310*1136*2085
- Trademark：Beyond
- Origin：China
- Production Capacity：100PCS,Month
Description
JZQJ Single Hydrocyclone Desander
Model JZQJ300×1 JZQJ250×1 JZQJ200×1 Hydrocyclone diameter 300mm 250mm 200mm Working pressure 0.2~0.45MPa 0.2~0.45MPa 0.2~0.45MPa Capacity 120m3/h 100m3/h 80m3/h Screen size 1240×585 mm 1240×585 mm 1240×585 mm Screen spec 120-200 120-200 120-200 Inlet diameter 6" 6" 3" Outlet diameter 8" 8" 6"
