• Model NO.：Mechanical
• Thread2：Btc, Ltc, Stc
• Usage：Oil (Gas) Production Machinery, Well Drilling Machinery, Offshore Oil and Gas Field Exploitation Machinery
• Power Type：Diesel
• Transmission System：Hydraulic
• Transport Package：Wooden Box
• Specification：5 1,2", 7", 9 5,8", 13 3,8"
• Trademark：zs
• Origin：Puyang City
• Production Capacity：100 PCS,Month

Basic Info.

Model NO. Mechanical Thread2 Btc, Ltc, Stc Usage Oil (Gas) Production Machinery, Well Drilling Machinery, Offshore Oil and Gas Field Exploitation Machinery Power Type Diesel Transmission System Hydraulic Transport Package Wooden Box Specification 5 1/2", 7", 9 5/8", 13 3/8" Trademark zs Origin Puyang City Production Capacity 100 PCS/Month

Product Description

9 5/8" L80 Mechanical two-stage collar for cementing

Description:

The multi-stage cementing collar provides an effective, economical way to cement one or more specific casing intervals or to cement upper zone saft era lower zone has been cemented. The collar should be used with centralizers aboce and below and a cementing basket positioned below the ports. The operation of the collar is simple and reliable. It features a double locking mechanism consisting of a snapring lock and ball lock system to assure that the ports are permanently locked closed after cementing is completed. Internal parts are designed to lock to prevent rotation during drill out and are constructed of easily drillable materials.

Features:

1.Opening pressure can be adjusted and it is not subjective to hole angle.
2.The pressure-relief design prevents fluid trapping and compression during the closing phase of the tool's operation.
3.The I.D of upper/lower sub is the same as that of casing, but smaller than that of closing sleeve, which can minimize chances of damages to the closing sleeve.

Technical Parameters:
