• Model NO.：115-152
• Name：Torque Anchor
• Thread：Eue
• Total Length：28inch
• Usage：Progressing Cavity Pump
• Transport Package：Wooden Case
• Specification：API
• Trademark：zx
• Origin：China
• HS Code：8431431000
• Production Capacity：3000PCS

Basic Info.

Model NO. 115-152 Name Torque Anchor Thread Eue Total Length 28inch Usage Progressing Cavity Pump Transport Package Wooden Case Specification API Trademark zx Origin China HS Code 8431431000 Production Capacity 3000PCS

Product Description

Torque anchor is a special anti-shedding tool which is designed for progressive cavity pump. During the operation of progressive cavity pump, it can effectively prevent the overturning of the tubular column until tripping and cause the tubing to fall down. The structure of this product is simple and anchored safe, which makes it easy to operate. This anchor greatly reduces operating costs and prevents the tubular column from bending.
The Torque Anchor is our newest torque anchor offering a reliable anchoring design at a reduced cost compared to other torque anchors.
when the tubing rotates clockwise, the anchoring floating slip bites into the casing wall whenever a reactive torque is developed. disengaging is done by rotating the tubing
counter-clockwise from surface.

Code	Case setup dia.[mm]	Connection[inch]
5-1/2	119…139	2 - 7/8 EU
7	152…172	2 - 7/8 EU or 3 - 1/2 EU
9-5/8 I	215…235	3 - 1/2 EU
9-5/8 II	220…240	3 - 1/2 EU

Application:

Apply with screw pump to avoid the stator and rotor rotate.

Operate instruction:
• Simple, easy operate.
• Stable anchor, easy release.
