• Design Temperature：-29-600ºC
• Main Materials：A105,Lf2,F304,F316,F51,F53,F51,F11,F22
• Seat Design：Integral Seat
• Seat Sealing Material：13cr,Stellite
• Transport Package：Wood Box by Sea
• Specification：ALL
• Trademark：XINHUAFA
• Origin：China Mainland
• HS Code：84139100
• Production Capacity：50000 Sets,Per Year

Basic Info.

Design Temperature -29-600ºC Main Materials A105/Lf2/F304/F316/F51/F53/F51/F11/F22 Seat Design Integral Seat Seat Sealing Material 13cr/Stellite Transport Package Wood Box by Sea Specification ALL Trademark XINHUAFA Origin China Mainland HS Code 84139100 Production Capacity 50000 Sets/Per Year

Product Description

Contact


Company	Hebel Xinhuafa Petroleum Machinery Co. LTD
Address	Chang'an District,Shijiazhuang,Hebei,China
Contacts	Anne Yang
Mobile	+8617831121697

Manufacturerst Forged gate valve/Forged gate valve / Gate Valve
Small size forged gate valves are used below 2inch gate valve, design as per API602/BS5352 with forged materials, and is mainly used to small size pipeline for oil & gas, water treatment, power station and other fileds, to cut/on off medium in pipeline.

Service	Oil, Gas, water treatment, power station and other pipeline.
Design Body	Bolted bonnet/Pressure sealing bonnet/Welded bonnet
Bore	Reduce bore/Full bore
Wedge type	Solid wedge
Design	Outside screw & Yoke, rising stem
Size	1/2"-24"
Pressure	150Lb-2500Lb
Design temperature	-29-600ºC
Main materials	A105/LF2/F304/F316/F51/F53/F51/F11/F22
Seat design	Renewable seat
Seat sealing material	13Cr/Stellite
Operation	Manual, Electric, Pneumatic,  Electro-hydraulic actuator. (Rotork, Biffi, DVG, ect.)
Design Standard	API602/S5352/DIN/GB/Ghost
Face to face	ASME B16.10/Ghost /DIN/GB /Manufacture's standard
Ends	RF/RTJ as ASME B16.5 , BW to ASME B16.25,SW to ASME B16.11 ,Thread ends as per ASME B16.11
Pressure and Temperature Design	ASME B16.34
Test standard	API598
Fire safe	APIF6A
Others	NACE MR0175/ISO15156(if applicable)
