Product Description

API 11B Sucker Rod

The sucker rod is used to make up the mechanical assembly between the surface and downhole components of a rod pumping system. The producr confirms to API specification 11B.



Feature

1) Material: Carbon steel, Alloy Steel
2) Grade: C, D, K, KD, HL, HY
3) Standard: API 11B
4) API and ISO certified
5) Size: 5/8'', 3/4'', 7/8'', 1'', 1 1/8"



Discription

a. Grade C sucker rod is made from fine carbon steel. It is featured by mid-strength, good plasticity, toughness, corrosion resistance. It is suitable for sour medium environment where it is not susceptible to sulphuric stress cracking.

b. Grade D sucker rod is made from fine alloy steel, featured by high strength, better plasticity and long service life after heat
treatment. This product is suitable for no-corrosion or light-corrosion environment oil-well widely.



c. Grade HL and HY sucker rods are super-high strength sucker rod, having the same size and main parameter as grade D sucker rod, but their strength is capable to reach 966~1195Mpa. Grade HL, HY sucker rods are suitable for the deep oil-well or big-pump capacity oil-well.



d. And grade K, KD and KH sucker rod are made from fine Cr-Ni-Mo alloy steel containing different amount of Ni. They possess more powerful anti-corrosion function. The products are suitable for strong corrosion oil-well, with depth of shallow, middle and deep respectively.



Advantage

a. Energy saving through pumping with a lighter string with no compromise in production;
b. Higher fluid production with existing pumping unit;
c. Reduction in the size of pumping unit with no reduction in production;
d. Increase pumps speed for additional production;
e. Extended service life and cost saving.
