6 3/4" (172mm) Straight Housing Oil Drilling Mud Motors
Glorytek Industry (Beijing) Co., Ltd.- Manufacturing Process:Forging
- Surface Treatment:Galvanized
- Operation Pressure:Atmospheric Pressure
- Material:Stainless Steel
- Keyword:Mud Motors
- Type:Petroleum Drilling Tool & Accessory
Base Info
- Model NO.:6 3,4"
- Certification:Ce, ISO
- Power Type:Diesel
- Transmission System:Hydraulic
- Transport Package:Seaworthy Packing
- Specification:,
- Trademark:Glorytek
- Origin:China
- Production Capacity:300 Sets,Month
Description
Recommended Hole SizeInput Flow Rate Pressure Loss Bit Speed Working Torque Delay Dynamic Torque Output Power Drilling Weight Max Drilling Weight Joint Thread Length Unit mm In L/S Mpa r/min N.m N.m KW KN KN In In mm 5LZ57×7.0 83-121 31/4-43/4 1.5-3.5 3.2 185-430 200 350 4.3-10.1 5 10 11/2REG 11/2REG 2822 5LZ73×7.0 83-121 31/4-43/4 2-4 3.2 80-160 615 1077 5.8-11.5 12 25 23/8REG 23/8REG 3423 9LZ89×7.0 105-143 41/8-55/8 3-8 3.2 147-392 504 882 8.64-23 20 30 27/8REG 27/8REG 2911 5LZ95×7.0 114-150 41/8-57/8 5-12 3.2 140-320 710 1240 10.5-25 21 40 27/8REG 27/8REG 3920 5LZ120×7.0 152-200 6-77/8 8-16 3.2 80-180 1850 3200 23-47 64 106 31/2REG 31/2REG 5039 5LZ165×7.0V 245-244 81/8-95/8 18-30 3.2 111-167 4440 7770 57.6-86.4 80 160 41/2REG 41/2REG 7408 5LZ165.5×7.0V 215-244 81/8-95/8 18-30 4.0 120-180 5135 8987 72-108 90 180 41/2REG 41/2REG 7748 5LZ172×7.0V 215-244 81/8-95/8 18-30 4.0 120-180 5135 8987 72-108 90 180 41/2REG 41/2REG 7391 5LZ172.5×7.0V 215-244 81/8-95/8 20-35 4.0 115-180 6452 11299 86.4-151.2 100 200 41/2REG 41/2REG 8031 7LZ172.5×7.0V 215-244 81/8-95/8 20-35 4.0 75-180 6527 11420 59.5-108.6 80 160 41/2REG 41/2REG 8631 5LZ185×7.0 215-244 81/8-95/8 20-35 4.0 184 5436 8154 80-140 120 240 41/2REG 61/2REG 8120 5LZ185.5×7.0 215-244 81/8-95/8 20-35 4.0 173 5939 8908 80-140 120 240 41/2REG 61/2REG 8120 5LZ197×7.0 244-311 91/8-125/8 20-40 3.2 61-122 14118 14118 57.6-115.2 120 240 51/2REG 65/8REG 7998 5LZ197.5×7.0 244-311 95/8-121/4 20-40 4.0 85-160 12640 12640 72-144 130 260 51/2REG 65/8REG 8598 7LZ203×7.0 244-311 95/8-121/4 20-40 3.2 70-155 12289 12289 57.6-126.7 150 240 51/2REG 65/8REG 7798 5LZ203.5×7.0 244-311 95/8-121/4 20-40 4.0 70-155 8778 15362 72-158.4 170 260 51/2REG 65/8REG 8598 5LZ216×7.0 273-323 103/4-123/4 22-48 3.2 61-138 8895 15567 63.36-138.29 190 300 65/8REG 65/8REG 7756 5LZ216.5×7.0 273-323 103/4-123/4 22-48 4.0 61-138 11117 19455 79.2-172.8 238 378 65/8REG 65/8REG 8546 5LZ244×7.0 311-445 121/2-171/2 50-75 3.2 91-136 15124 26468 144-216 200 360 65/8REG 75/8REG 8635 7LZ244.5×7.0 311-445 121/2-171/2 50-75 4.0 91-136 18905 33085 180-270 250 450 65/8REG 75/8REG 9235
