Petroleum Walking Beam Pumping Unit Jack Oil Pump Jack C228
Shandong Seaco Machinery Equipment Co., Ltd.- Condition：New
- Transmission：Mechanical
Base Info
- Model NO.：API 11E Walking Beam Pumping Unit Jack oil Pump Ja
- Pumping Way：With Rod
- Type：Conventional Beam
- Gear Box：API Standard
- API：11e
- Motor：Electric Motor
- Belt：Motor Belt
- Brake：with Brake Assy
- Spare Parts：Bearings
- Model：C22 C320 C456
- Material：Carbon Steel
- Paccessories：Polished Rod Clamps
- Transport Package：Standard Export Packing
- Specification：C228 C320 C456
- Trademark：SEACO
- Origin：Shandong China
- HS Code：84314310
- Package size per unit product：11600.00cm * 2250.00cm * 2200.00cm
- Gross weight per unit product：23500.000kg
Description
| NO. | Designation | Structure Capacity(lbf×102) | Stroke(in) | Strokes per minute | Motor Type | Reducer torque (103lb.in) | Total mass(t) | Unit sizeL W H (m) |
| 1 | CW114-109-100HF | 109 | 100,86,67 | 5,7,9 | Y200L-8 | 114 | 11.1 | 7.0×1.9×6.6 |
| 2 | CW160-109-100HF | 109 | 100,86,67 | 5,7,9 | Y200L-8 | 160 | 12.1 | 7.0×2.0×6.6 |
| 3 | CW160-133-120F | 133 | 120,100,86 | 5,7,9 | YMJ180L-6 | 160 | 13.2 | 7.9×2.0×6.9 |
| 4 | CW160-173-120F | 173 | 120,100,86 | 6,8,10 | Y225S-8 | 160 | 15.5 | 8.1×2.0×6.9 |
| 5 | CW228-173-100F | 173 | 100,86,64 | 6,8,10 | Y225S-8 | 228 | 14.9 | 8.1×2.2×6.7 |
| 6 | CW228-173-120HF | 173 | 120,100,86 | 6,8,10 | Y200L1-6 | 228 | 14.9 | 7.6×2.1×6.9 |
| 7 | CW228-173-120F | 173 | 120,100,86 | 6,8,10 | Y225S-8 | 228 | 16.2 | 8.1×2.2×6.9 |
| 8 | CW160-200-74F | 200 | 74,64,48 | 6,9,12 | Y225M-8 | 160 | 14.7 | 8.1×2.2×6.7 |
| 9 | CW160-213-74F | 213 | 74,64,48 | 6,9,12 | GAS ENG. | 160 | 14.7 | 8.1×2.2×6.7 |
| 10 | CW228-213-100F | 213 | 100,86,74 | 6,8,10 | Y250M-8 | 228 | 20.1 | 8.1×2.1×6.7 |
| 11 | CW456-213-192HF | 213 | 192,168,144 | 4,6,8 | Y250M-8 | 456 | 25.8 | 11×2.52×9.5 |
| 12 | CW228-256-100F | 256 | 100,86,74 | 6,8,10 | Y250M-8 | 228 | 20.6 | 8.1×2.1×6.7 |
| 13 | CW228-256-100F | 256 | 100,86,74 | 6,8,10 | GAS ENG. | 228 | 20.6 | 8.1×2.1×6.7 |
| 14 | CW320-256-144F | 256 | 144,120,100 | 5,7,9 | Y280S-8 | 320 | 23.3 | 8.9×2.3×7.8 |
| 15 | CW456-256-144F | 256 | 144,120,100 | 5,7,9 | Y280S-8 | 456 | 25.5 | 8.9×2.3×7.8 |
| 16 | CW456-256-192HF | 256 | 192,168,144 | 4,6,8 | Y250M-8 | 456 | 26.3 | 11×2.52×9.5 |
| 17 | CW640-256-192HF | 256 | 192,168,144 | 4,6,8 | Y280M-8 | 640 | 29.2 | 10.9×2.52×9.8 |
| 18 | CW320-305-120F | 305 | 120,100,86 | 6,8,10 | Y280S-8 | 320 | 23.6 | 8.7×2.3×7.5 |
| 19 | CW320-305-120F | 305 | 120,100,86 | 6,8,10 | GAS ENG. | 320 | 23.6 | 8.7×2.3×7.5 |
| 20 | CW456-305-144F | 305 | 144,120,100 | 6,8,10 | Y280M-8 | 456 | 26.9 | 10×2.6×9.1 |
| 21 | CW456-305-168HF | 305 | 168,144,120 | 5,7,9 | Y280M-8 | 456 | 29.7 | 10.5×2.9×9.6 |
| 22 | CW640-305-168F | 305 | 168,144,120 | 5,7,9 | Y280M-8 | 640 | 32.6 | 10.8×2.9×9.1 |
| 23 | CW912-305-168F | 305 | 168,144,120 | 5,7,9 | Y315S-8 | 912 | 37.2 | 10.7×2.9×9.1 |
| 24 | CW640-305-192HF | 305 | 192,168,144 | 5,7,9 | Y280M-8 | 640 | 34.7 | 11.8×2.9×9.5 |
| 25 | CW640-365-192F | 365 | 192,168,144 | 4,6,8 | Y315S-8 | 640 | 34.9 | 11.3×2.9×9.6 |
| 26 | CW912-365-192F | 365 | 192,168,144 | 4,6,8 | Y315S-8 | 912 | 39 | 12.0×2.9×10.4 |
| 27 | CW912-365-216HF | 365 | 216,192,157 | 4,6,8 | YMJ280S-8 | 912 | 39.4 | 12.0×3.1×10.8 |
